Ion implantation is the most useful technology for doping of 4H silicon carbide to fabricate power devices. For n-type doping, nitrogen is the most common element used in device fabrication due to its low atomic mass and proven applicability in epitaxial n-type SiC. Phosphorus can be an alternative to nitrogen (N) for providing a lower sheet resistance, although the research on phosphorus as a dopant is limited [1-3] in range of doping and activation temperatures. A rigorous study comprising different doping concentrations would help to verify the activation percentage and ionization energies and will lead to a better understanding of the properties of dopants other than N, to take advantage of any underlying benefits. In this work, phosphorus is implanted in different concentrations on 150 mm Si-face 4H SiC (0001) of 4 degree off-axis wafers and activated above 1600 oC. To study the electrical characteristics, circular van der Pauw structures were made. Deep p-well implants were performed to isolate the phosphorus doped region from the n-type substrate. Nickel contacts were deposited using evaporation and post-annealed at high temperature to get ohmic contacts. The samples were then placed on a 1cm x 1cm PCB board with 4 contacts at the corners, and wire bonding from sample to board was performed. Following that, 4-point probe resistance and Hall measurements were conducted to obtain resistivity, carrier concentration, and Hall mobility for different doping levels. Thereafter, dopant activation percentage and ionization energy levels are calculated. Figure 1 shows typical IV characteristics of the fabricated van der Pauw samples that indicate linear or ohmic behavior of the contacts. Figure 2 shows the temperature-dependent variation of resistivity for different doping levels. From 150 to 300 K the resistivity drops as temperature increases, while above room temperature a small increase of resistivity can be observed. An increase in the carrier concentration versus temperature is shown in Fig. 3, for doping less than 9x1019 cm-3. The sample with a doping concentration of 9x1019 cm-3 behaves like a semimetal for which the carrier concentration is almost constant with changing temperature. A small upshoot in carrier concentration at very low temperature (~150 K) might be caused either by a change of effective implant thickness with temperature, or p-well dopant freeze out effects underneath the n-wells. Figure 4 shows mobility versus temperature for different Phosphorus implanted concentrations. At lower temperatures mobility drops due to increased ionized impurity scattering. Mobility reaches a peak value near room temperature and drops again as temperature increases due to increased phonon scattering owing to enhanced lattice vibrations. Figure 5 shows the carrier concentrations as modeled in hexagonal and cubic lattice sites (50:50 distribution assumed) with assigned specific ionization energies. For example, for the sample with implanted doping concentration of 4x1018 cm-3, the ionization energies are extracted to be 48 and 110 meV for hexagonal and cubic lattice positions from the model fit. The values of activated dopants are also calculated here from this analysis and plotted as a function of doping concentrations as shown in figure 6. It is clear that the phosphorus activation is well below 100%. The extracted activation percentages and dopant ionization levels will be shown for all samples, and compared to literature values, in the full manuscript. The activation percentages and ionization energies, extracted from the data, will be useful for calibration of Technology Computer Aided Design (TCAD) models for electrical simulations of 4H-SiC based devices. [1] M.A. Capano et al., J. Electron. Mater. 29, 210 (2000). [2] J. Gardner et al., J. Appl. Phys. 83, 5118 (1998). [3] T. Kimoto, J.A. Cooper, Fundamentals of Silicon Carbide Technology (2014).

EMC 2023

Study of Dopant Activation and Ionization for Phosphorus in 4H-SiC

activation

ionization energy

hall measurements
