Assessment of transistor degradation in analog circuits during aging effect is challenging due to wide spread of operating points. This paper presents our proposed characterization approaches of full ID-VG
degradation for large and nanoscale devices respectively. Threshold voltage shift and mobility degradation in large devices can be extracted simultaneously with fast measurement speed (tm=3us). Based on this, full ID-VG
degradation can be assessed intuitively. Impacts of individual defects on full ID-VG degradation in nanoscale devices are characterized with the proposed approach with high resolution. Thus this paper provides a helpful solution to the characterization of device degradation in analog circuits.

IRPS 2022 Main Conference

Towards the Characterization of Full ID-VG Degradation in Transistors for Future Analog Applications
