Periphery pFETs fabricated with the sub-20nm technology are investigated under hot carrier stress conditions when the gate voltage (|Vg|) is lower than the drain voltage (|Vd|). Two types of defects are identified: the donor-like interface trap generation causes the positive charge formation while the electron trapping in oxide traps leads to the negative charge accumulation. The corresponding energy and spatial locations are identified by analyzing the defect-induced mobility degradation and the recovery characteristic. Finally, a defect-based model is proposed for both the threshold voltage shift and the mobility degradation, which allows the prediction of the full IV after aging. This work paves a new avenue to develop accurate reliability model of periphery pFETs, a prerequisite for future device/circuit co-optimization in DRAM peripheral circuits.

IRPS 2022 Main Conference

Characterization and Modelling of Hot Carrier Degradation in pFETs under Vd&gt;Vg Condition for sub-20nm DRAM Technologies

oxide trap

interface trap

hot carrier degradation

dram
