CV characteristics of MOS capacitors are classically measured in a few seconds using a capacimeter. Yet it limits the range of useful characterization that can be performed on these devices. For instance BTI reliability characterization is limited by the unavoidable recovery during every measurement step. Likewise, it is almost impossible to characterize properly the hysteresis effect present in some oxides.  Therefore we propose new ultra-fast and powerful CV techniques for MOScap, able to overcome the time limitations of former techniques.


IRPS 2022 Main Conference

Ultra-fast CV methods (&lt; 10µs) for interface trap spectroscopy and BTI reliability characterization using MOS capacitors

high-k oxide

cmos technology

semiconductor device reliability

aging
