The electron trapping in gate oxides of m-plane SiC-MOS capacitors were studied by electron injection. The trapped electron densities calculated using the flat-band voltage shift were analyzed. There are possibly three types of electron traps with different capture cross sections. The oxide grown by LPCVD has slightly lower electron trap density than the oxides by thermal oxidation or TEOS-PECVD. The obtained trapped electron densities were found to be one order of magnitude higher than that of Si-MOS and there may be large room for improvement of the electron trap in the gate oxide of SiC-MOSFET for better VT reliability.

IRPS 2022 Main Conference

Characterization of Electron Traps in Gate Oxide of SiC MOS Capacitors
