Optical metasurfaces have emerged as potential candidates for next generation optical devices due to their ability to manipulate the amplitude, phase, wavenumber, and polarization of light1. They are two dimensional subwavelength structures which are engineered to abruptly impart a desired property shift to the impinging optical wavefront. Huygens metasurfaces comprise of an array of optical resonators where each resonator acts as a point source causing light to propagate in the forward direction. In our work, these metasurfaces are made using vanadium dioxide, which was chosen as a good candidate because it exhibits a reversible metal-insulator transition above 68oC. Vanadium dioxide is known for its thermochromic property, making it a promising material for smart energy-saving windows2. In this report, we present a bottom-up fabrication process for vanadium dioxide metasurfaces useful for optical modulation at short wave infrared wavelengths (SWIR). Thin films of vanadium dioxide are fabricated using pulsed laser ablation of a vanadium pentoxide target on a quartz substrate. This is done using a KrF excimer laser while flowing oxygen gas into the vacuum chamber during ablation. Electron-sensitive resist (PMMA) is spun on the film and functions as a stencil for patterning using electron beam lithography. Different hard masks have been used to achieve etched features that closely match geometries designed using finite element analysis for specific behaviors. We present results of fabricated nanoantennas using fluorine- and chlorine-based etch processes. We propose that chlorine-based etch recipes are preferred in order to achieve good anisotropy and accurate nanoscale dimensions for optical device applications.

EIPBN 2021

Fabrication of Dynamically Tunable Vanadium Dioxide Huygens Metasurfaces for Optical Modulation

optical modulation

phase transition material

vanadium dioxide
