In spite of M-C simulation shows strong dependence proximity function on depth (3D-PF)  it is possible to find effective α, β, η parameters for two-dimensional PF using original algorithm which considers development. Good agreement with experimental data is demonstrated thus proximity parameters now can be calculated for arbitrary layered material

EIPBN 2021

PRESENTATION OF PROXIMITY FUNCTION BY THREE PARAMETERS , , BASED ON MONTE CARLO METHOD AND COMPARISON WITH EXPERIMENT
