We introduce a UV greyscale lithography process combining large surface patterning with a high vertical resolution. To reach a low contrast curve slope, we studied the annealing processes Soft Bake and Post Exposure Bake. We also achieve a 50nm Si steps within our presented plasma etching process.

EIPBN 2021

Optimized UV grayscale process for high vertical resolution applied to spectral imagers

spectral imagers.

fabry-perot interferometers

grayscale lithography

The International Conference on Electron, Ion and Photon Beam Technology and Nanofabrication (EIPBN), affectionately known as "3-Beams," is the premier gathering of scientists and engineers who are dedicated to electron, ion and photon lithography, imaging, and analysis; atomically precise fabrication; nanofabrication process technologies and related emerging technologies; and their applications in a broad spectrum of fields. In its 64th meeting, researchers from academia, government laboratories, and industry from around the world meet to present and discuss recent and future trends in these technologies.
