The goal of this work is to build compartmentalized microelectrode arrays to assess the impact of conditioned cell culture media exchange between two initially isolated neuronal networks. The fabrication of biocompatible dual-chamber microelectrode arrays is presented, including the manufacturing and attachment of resin rings with controllable openings for fluid exchange.
