Two-dimensional (2D) materials possess various intriguing properties, making them promising building blocks for future nanoelectronics. For example, 2D semiconductors offer sizable mobilities and high on-currents in thin layers, allowing for excellent gate control in scaled transistors. Nonetheless, to bridge the gap between current device prototypes and commercial applications, multiple challenges must be overcome, including identifying gate stacks that are both scalable and allow for reliable operation throughout the device’s lifetime.

IRPS 2024 Tutorials and YIR

Reliability of Nanoelectronics based on Two-Dimensional Materials

#### Welcome to the 60th IEEE International Reliability Physics Symposium (IRPS)!

[![](https://assets.underline.io/uploads/markdown_image/1/image/f6b8cf9ecca2209dd3e0fcebe80a2915.png)](https://underline.io/events/282/reception) [![](https://assets.underline.io/uploads/markdown_image/1/image/e787ff477f8d2b687fb0b54d83d35e11.png)](https://drive.google.com/drive/folders/1GAycr7pPrZG2ZzZP-geUL8vGWswjCB1N?usp=sharing) [![](https://assets.underline.io/uploads/markdown_image/1/image/7492fafcc0c623afe96fe15207855ed9.png)](https://www.irps.org/)


**General Chair Welcome Message**

Welcome to IRPS 2022! When the IRPS Management Committee began making plans for Dallas, we recognized the strong desire by the reliability physics community to return to a face-to-face symposium that we last had in Monterey in 2019. But as time progressed, we recognized that travel restrictions were not being lifted as rapidly as we anticipated. Rather than leave out those of you who could not attend in person, we adopted a hybrid format allowing for both remote attendance and remote presentations. This is a first for IRPS and I am confident it will be a success for all.

With this new hybrid format, the symposium will return to the original five-day format with Tutorials and Year in Review on the first two days. The Technical Program, Keynote Talks, Workshops and Poster session will be held on the following three days. All of these (except Workshops and Posters) will be available via real-time streaming in the US Central Time zone with virtual attendees having Q&A access to the presenters. For those virtual attendees who cannot watch the live presentations, the material will be available on demand to all attendees for a month after the symposium with the ability to communicate with the authors.

In 2020, we were planning on co-hosting the International ESD Workshop (IEW) ESD workshop when the COVID-19 pandemic hit. For 2022, IEW will be seamlessly embedded into the IRPS Program and will sponsor three tutorials, an invited talk, two technical sessions and two evening workshops focused on ESD and latch-up. And we continue our
collaboration with our sister conference, European Symposium on Reliability of Electron Devices Failure Physics and Analysis (ESREF) by hosting their Best Paper and the International Integrated Reliability Workshop (IIRW) by hosting their Best Student Paper.

Our primary objective is to maintain the symposium’s leadership role in the reliability physics of microelectronic devices by attracting leading researchers to present their work and providing attendees the best place to access this information. With all the buzz in the media about whether Moore’s Law has hit its limit, IRPS has been promoting expertise developed in silicon-based reliability over the past sixty years and expanding into new material areas. This year, eight of the technical sessions are devoted to reliability in topics outside of traditional silicon, including wide bandgap GaN/SiC, emerging memory and neuromorphic computing. I hope our ability to draw these communities together will accelerate the cross-fertilization of ideas.

The Technical Program consists of four keynote speakers, twenty-three invited speakers and eighty-seven oral presentations organized in thirty technical sessions on eighteen reliability topics. Over two evenings, there will be ten Workshops and sixty-six Poster presentations that are designed to allow in person attendees and experts to interact
with one another. With eighteen tutorials covering topics ranging from fundamental transistor and memory reliability all the way up to automotive and complex system-level reliability, this year’s symposium provides an excellent learning opportunity for engineers and scientists new to reliability as well as experienced individuals wanting to explore new
areas. The Year in Review, which serves as a summary of research in the past year, will cover 3D packaging, emerging memory and aging aware circuit designs.

Finally, I would like to express my extreme gratitude to our patrons and exhibitors, whose support makes IRPS possible.
And to all of you, our in person and virtual attendees, for supporting this symposium for sixty years!

**Charles W. Slayman, General Chair**
**of 2022 IRPS Management Committee**

**About IRPS**

The IEEE International Reliability Physics Symposium (IRPS) is the premiere conference for engineers and scientists to present new and original work in the area of microelectronics reliability. Drawing participants from the United States, Europe, Asia, and all parts of the world, IRPS seeks to understand the reliability of semiconductor devices, integrated circuits, and microelectronic assemblies through an improved understanding of both the physics of failure as well as the application environment. IRPS provides numerous opportunities for attendees to increase their knowledge and understanding of all aspects of microelectronics reliability, and to meet and network with reliability colleagues from around the world.

Please log in to explore this event. You need to log in with the email address you registered with. Access credentials have been sent to your email.

Please log in to explore this event.

Registration for this conference has now closed. We appreciate your interest and hope to welcome you at a future event. If you’d like to hear about similar upcoming events, please check our website or join our mailing list.

Registration for this conference has now closed.

IRPS 2022 Main Conference

IRPS provides numerous opportunities for attendees to increase their knowledge and understanding of all aspects of microelectronics reliability. It is also an outstanding chance to meet and network with reliability colleagues from around the world.

tutorial

**IRPS 2024 Tutorials were held in Dallas, Texas from April 14 to 15, 2024. The IRPS Reliability Year in Review (YIR) session consisted of three presentations reviewing the past year's reliability work by experts in the field for areas of high interest. It was a nice augmentation to the tutorials sessions immediately preceding and attendees were able to obtain keen reliability insights in short amount of time.**

[![](https://assets.underline.io/uploads/markdown_image/1/image/31e631d9941728874f1cea6ddf221cd4.png)](https://underline.io/events/445/reception)
[![](https://assets.underline.io/uploads/markdown_image/1/image/a6a3fb1b1830527791842ee5c8f13e6c.png)](https://www.irps.org/)
[![](https://assets.underline.io/uploads/markdown_image/1/image/35139d437e3e8a3413aa4c1f0d2c5400.png)](https://drive.google.com/drive/folders/1Iy0QiBLQlf17nt_xBrqLLvY9_rPaFhDn?usp=sharing)


**[IRPS 2024 eGuide](https://drive.google.com/file/d/1DHxkWbafodK_D2HlDi7lwRK7KatgBgBD/view?usp=drive_link)**
Please save the zip file locally and click the "start.pdf" to view the file.

**IRPS 2024 General Chair Welcome Message**

On behalf of the Management Committee of the IEEE International Reliability Physics Symposium (IRPS) and the IRPS Board of Directors, it gives me great pleasure to extend a warm welcome to all who are planning to attend the IRPS 2024, scheduled to take place from April 14-18, 2024, in Dallas, TX.
Over its 62-year history, IRPS has solidified its position as the premiere conference for engineers and scientists to present new and original work in the field of microelectronics reliability. Drawing participants from the United States, Europe, Asia, and other parts of the world, IRPS aims to deepen our understanding of reliability of semiconductor devices, integrated circuits, and microelectronic assemblies through an improved understanding of both the physics of failure as well as the application environment. IRPS offers diverse opportunities for attendees to enhance their knowledge and understanding of all aspects of microelectronics reliability. It is also an outstanding chance to meet and network with reliability colleagues from around the world.

The IRPS 2024 technical activities will begin with two days of a total of twenty tutorial sessions covering a broad spectrum of emerging reliability topics beyond CMOS device, circuit and system reliability. These sessions are devoted to both newcomers as well as experts. Three reliability Year in Review (YIR) talks focusing on neuromorphic computing, dielectric breakdown in leading edge devices, and GaN technology will be provided on Monday after the tutorials.

The IRPS 2024 technical program will feature four distinguished keynote talks in the plenary sessions delivered by Prof. Shinichi Takagi from The University of Tokyo and Dr. Su Jin Ahn from Samsung on Tuesday, Dr. Rajeev Malik from IBM on Wednesday, and Dr. Sameer Pendharkar from Texas Instruments on Thursday. The technical program, organized into three parallel tracks, consists of contributed and seventeen invited papers from leaders in industry and academia. Additionally, two invited talks by recipients of paper awards from our sister conferences, European Symposium on Reliability of Electron Device Failure Physics and Analysis (ESREF) 2023 and the International Integrated Reliability Workshop (IIRW) 2023, will be given in the technical program.

Tuesday evening will host ten workshops, offering an opportunity for in-depth, face-to-face discussions on emerging reliability challenges, including the three IRPS 2024 focus topics. A poster session will be held in the Austin Ranch outside the symposium building on Wednesday evening. Both events are sure to be lively. The IRPS 2024 and the International ESD Workshop (IEW) will be co-hosted with IEW registrants participating in both IRPS and IEW programs.

The IRPS 2024 will adopt a hybrid conference style, allowing virtual access to live oral presentations hosted by the Underline. Real-time streaming of all technical events (excluding Workshops and Posters) will be available in the US Central Timezone, providing virtual attendees with Q&A opportunities. For those virtual attendees who cannot watch the live presentations, the material will be available on demand to all attendees after the symposium. All authors will be presenting in person.

Finally, I would like to extend my extreme gratitude to our patrons, exhibitors, and all participants for their invaluable support, which makes IRPS successful.

Please enjoy the IRPS 2024!

Koji Eriguchi, General Chair
of 2024 IRPS Management Committee

**About IRPS**

The IEEE International Reliability Physics Symposium (IRPS) is the premiere conference for engineers and scientists to present new and original work in the area of microelectronics reliability. Drawing participants from the United States, Europe, Asia, and all parts of the world, IRPS seeks to understand the reliability of semiconductor devices, integrated circuits, and microelectronic assemblies through an improved understanding of both the physics of failure as well as the application environment. IRPS provides numerous opportunities for attendees to increase their knowledge and understanding of all aspects of microelectronics reliability, and to meet and network with reliability colleagues from around the world.

You need to log in with the email address you registered with. Access credentials have been sent to your email.

Please be sure to check your spam and other email folders if you do not see an email confirmation right away.

It looks like you are not registered for this event.

To access the site please register [**here**](https://www.irps.org/registration-fees).

Please register!

The IEEE International Reliability Physics Symposium (IRPS) is the premiere conference for engineers and scientists to present new and original work in the area of microelectronics reliability. IRPS seeks to understand the reliability of semiconductor devices, integrated circuits, and microelectronic assemblies through an improved understanding of both the physics of failure as well as the application environment.

In this tutorial, I will give a brief introduction to reliability and failure analysis fundamentals; review key reliability aspects for SiC devices such as bias temperature instability, bipolar stability due to Shockley stacking faults, gate oxide reliability, humidity effects, reverse bias, single event burnout and power cycling; illustrate mission profile analysis techniques; review essential failure analysis techniques such as fault detection, FIB/SEM and EBIC; and review the latest industry consortia standards and guidelines.

SiC Device Reliability and Failure Analysis

Design Technology Co-optimization (DTCO) has become a critical part for new technology development and applications.  For high end and critical application products, reliability co-optimization is an important integral part of DTCO.  This tutorial focus on the interconnect reliability optimization considerations for chip design.  Discussions will be made from understanding the intention and limitation of various design guidelines & reliability limits to identifying critical areas and robust layouts for different interconnect reliability mechanisms for chip design.

Interconnect Reliability for Chip Design

Hot-carrier degradation (HCD) is a major reliability concern in current and upcoming CMOS technology nodes. In this tutorial, we describe the properties and physical understanding of this FET aging mechanism. We then briefly review past HCD models and explain in depth the modeling of HCD for current technologies. We also address the related problem of self-heating and its interaction with HCD. Additionally, we review different strategies which are used to counteract HCD.

Hot-carrier Degradation in MOS Transistors

5/6G implementation will enhance mobile broadband service in more ways than the user can imagine. 5/6G will create a unified wireless network operating on a global scale, enabling uses far beyond just consumer-oriented devices. Manufacturers must validate reliability to standards of emerging industry as well as standards already in traditional markets. How can the technical team arm sales and marketing with data to convince customers that un-fielded products will work reliably in the intended environment?

From Fabrication to Field: The Importance of Semiconductor Reliability Testing in the Age of Wireless Transformation

GaN utilization in RF communications systems is expanding. Reliability assessment of GaN largely follows proven techniques of static stress conditions to quantify acceleration mechanisms predicting long term degradation, along with short term transient stress conditions. These test methods do not assess multiple stress conditions’ impact and interaction during operation of complex RF/microwave/mmWave circuits. This tutorial presents fundamental RFOLT methods, discusses the complex stress conditions introduced and the value of RFOLT assessing device and circuit reliability.

GaN RFOLT for 5G/6G Applications

PID is discussed from the fundamentals to the complex “well charging”. A full description of the PID failure mechanism sets a common understanding for the need of a comprehensive qualification procedure including antenna ratio definition, test structures, stress methods, key analysis parameters for silicon-bulk and SOI technologies. Well charging is under discussion to define antenna design rules for a reliable productive design rule checker. Two competing methods are described from literature with brand-new findings.

Plasma Induced Damage (PID): From Basics to Complex Well Charging

To meet the growing demand for integrated circuits (ICs) in increasingly complex and demanding applications, the semiconductor industry has evolved dramatically during the past few decades. Military, space, and avionic electronics must survive harsh environmental conditions, requiring highly reliable specialized packaging like 2.5D/ 3D hetero integration (HI) for greater functionality, device density, and speed. Thus, cross-coupled chip-package-board interactions (CPBIs) result from the proximity of a wide variety of active and passive components and material stacks and processes. This tutorial will provide insights into the emerging electrical reliability challenges typical of a 2.5D/3D packaged IC and offer potential solution schemes to ensure reliable IC operation under the most stringent conditions.

Electrical Chip-Package-Board Reliability of 2.5D/3D Heterogeneously Integrated Systems

We review the drift of MOS devices parameters and the MOS device gate dielectric breakdown in off-state mode. Non-conducting hot carrier may induce significant drift of digital and I.O. devices in overdrive conditions, High voltage asymmetrical devices, power switches as well as RF devices.

Gate dielectric breakdown is critical not only as a parasitic phenomenon occurring while performing accelerated non-conducting HCI stress but also can be a limiting factor for High Voltage asymmetrical MOS devices.

Effect of OFF-State Stress on CMOS Devices

The growing complexity of today’s automotive vehicles goes side by side with increasingly stringent and multifaceted safety requirements. Just like electromechanical systems in a car, semiconductor components now need to demonstrate high levels of reliability against a variety of failure modes, out of which radiation effects could arguably be among the most unpredictable at system level. While cosmic-ray induced errors may be rare at sea level, the sheer number of land vehicles in a manufacturer’s….

New Industrial Radiation Paradigms for LEO Satellite Constellations, Full Autonomous Car Driving and Sovereign 3D Chiplets

Recent advances in automotive SOCs, AI accelerators, and HPC engines in data centers have led to an explosion in the adoption of emerging technology nodes and 3DIC/chiplet packages. We will discuss the resiliency challenges for these emerging SOCs, and optimizing the SOC health using prognostics, test and analytic solutions, utilized for managing silicon lifecycle (SLM) for improving quality and yield; and also address aging and degradation challenges for improved RAS and functional safety.
