Technology Computer Aided Design (TCAD) tools are well established for modeling semiconductor fabrication processes, and device operations. This tutorial provides an overview how TCAD can is for modelling of various reliability issues, including mechanical stresses introduced during manufacturing process or device operations, Electrostatic Discharge (ESD), latch up/junction breakdown, Hot Carrier Degradation (HCD) and Negative Temperature Bias Instability (NTBI) and Time Dependent Dielectric Breakdown (TDDB), modeling of charge loss mechanics in 3D NAND memories, and others.

IRPS 2024 Tutorials and YIR

TCAD for Reliability
