This tutorial aims at presenting an overview of degradation phenomena that lead to dielectric breakdown. We discuss how dielectric degradation can be observed and show possible consequences for device operation. An important aspect of TDDB is a correct description of its statistics, that can be derived from individual defect generation dynamics. We look at modeling approaches and ways of calculating the time-to-breakdown. We also discuss differences and similarities of breakdown in FEOL, MEOL and BEOL.

IRPS 2024 Tutorials and YIR

Understanding and modeling Time-Dependent Dielectric Breakdown
