We present a comprehensive study on the gate stack TDDB challenges in Gate-all-around (GAA) nanosheet (NS) transistors (FETs), including volume-less multi-Vt integration and patterning, the performance and reliability trade-off in inner spacer (IS) module, and the impact from Si channel geometry on gate stack reliability. These scaling associated challenges served as strong motivators and will continue to drive process-reliability co-optimization efforts towards optimum performance while preserving robust TDDB reliability.

IRPS 2024 Main Conference

Challenges of gate stack TDDB in gate-all-around nanosheet towards further scaling
