In this paper, we present a detailed study of negative bias temperature instability (NBTI) and Time dependent dielectric breakdown (TDDB) reliability in p-type stacked gate- all -around (GAA) Nanosheet (NS) transistors with SiGe channel and compared with NS Si pFETs. Robust NBTI and TDDB reliability performance is achieved on SiGe gate-all-around NS.


IRPS 2022 Main Conference

SiGe Gate-All-around Nanosheet Reliability
