In this work we develop a retention model of 3D NAND and: (1) show importance of the blocking oxide quality improvement and lateral migration suppression (through alternative integration schemes) as a key retention enhancer; and (2) develop a superior SiO2 with low defectivity and demonstrate a direct relationship between blocking oxide, SiO2 defectivity and data loss during retention.

IRPS 2024 Main Conference

Blocking oxide material engineering to improve retention loss in 3D NAND: a modeling process optimization study
