In this work, we evaluate the scaling limits of inter-word line dielectrics for 3D NAND Flash devices. We test different oxide stacks by mimicking the stacked architecture using planar capacitors. We conclude that a ~17% reduction in stack height, from 24 nm to 20 nm, can be obtained by removing the High-K liner from the top and bottom of the SiO2, without compromising device reliability.

IRPS 2024 Main Conference

P27.MR -Exploring the Reliability Limits for the Z-Pitch Scaling of Molybdenum Inter-Word Line Oxides in 3D NAND
