This work investigated the statistical modeling for post-programming conductance drift of 3-bit analog RRAM. We proposed a novel criterion, WRMSE, to substantiate that the conductance drift ought to be separated into two distinct phases: relaxation and RTN. We further developed a compact model based on CTMC to capture the variation of post-programming conductance distribution. The established model could provide useful guidelines for the future design of analog-RRAM based neuromorphic computing systems.

IRPS 2024 Main Conference

Statistical Modeling of Time-Dependent Post-Programming Conductance Drift in Analog RRAM

analog rram

compact model

neuromorphic computing
