The impact of Program/Erase (P/E) cycling on Cell VT Distribution (CVD) during retention bake in 3-D NAND Charge Trap Flash (CTF) arrays is modeled. Experimental data under Solid Pattern (SP) test is analyzed using Activated Barrier Double Well Thermionic (ABDWT) model. Only two adjustable parameters can model DR loss across various P/E cycles, Bake Temperature (BT), Programming Levels (PL) and CVD levels (sigma). The relative contributions from the underlying physical mechanisms are determined.

IRPS 2024 Main Conference

Modeling of Post-Cycling Retention Bake in 3-D CTF TLC NAND Arrays

abdwt model

data retention

nand flash memory
