Temperature-accelerated methods are generally used for lifetime evaluations in Flash memories products. However, in this article, an anomalous negative temperature dependence of erase-state threshold voltage (Vt) retention gain in post program/erase (P/E) cycled 3-D NAND Flash memories is reported for the first time, which would lead to a methodological problem of the conventional temperature-accelerated life-test approach. Based on our experiment results, the phenomenon is realized due to the combination of two physical mechanisms. Erase Vt gain at lower temperatures is mainly attributed to silicon nitride (SiN) trapped hole vertical loss via oxide trapped charges created by high P/E cycling stress. At higher bake temperatures, the influence of oxide trapped electron detrapping process is enhanced and Vt gain is therefore reduced. By performing a special experiment, the activation energy of the trapped electron detrapping process is extracted.

IRPS 2022 Main Conference

An Abnormal Negative Temperature Dependence of Erase-state Vt Retention Shift in 3-D NAND Flash Memories
