From over 50 years, dielectric breakdown is a crucial reliability concern in electron devices. Despite various theories accurately replicating breakdown trends in accelerated conditions, discrepancies arise in estimating device lifetime under operating conditions. The latest Carrier Injection (CI) model harmonizes these inconsistencies, revealing dynamic changes in time-to-breakdown E-field dependence. By incorporating trapped charges into CI model, we present a more comprehensive understanding of breakdown, demonstrating that trapped charges enhances reliability by delaying trapping into precursors.

IRPS 2024 Main Conference

The Major Effect of Trapped Charge on Dielectric Breakdown Dynamics and Lifetime Estimation

charge injection

trapped chage

breakdown
