Aluminum nitride (AlN) is considered a future candidate for the future power electronics applications for its wide bandgap (6.2 eV), high thermal conductivity (340 W/mK), and high breakdown field (~12 MV/cm). However, due to the challenges in material growth and device fabrication, very limited work has been reported on AlN electronics, and the full potential of AlN material is yet to be discovered. The impact ionization (II) coefficients, which determine the blocking limits of AlN power devices is still both experimentally and theoretically imprecise but is under study at present. Here we collected the different II coefficients reported in the literature and analyzed their impacts on the device performance with TCAD Silvaco. The quasi-vertical AlN Schottky diode is simulated in Silvaco TCAD environment. Selberherr’s II model is employed to analyze the breakdown performance of the device as: αn,p=an,pexp(-bn,p/E) Where α is the II coefficients, E is the electric field, and a, b are the parameters need to be determined. 3 II coefficients are collected from the theoretical results reported, which have a large discrepancy: one calculated from the full-band Monte Carlo model in E. Bellotti et al. [1], one calculated from the ensemble Monte Carlo framework in C. Bulutay et al. [2], and one in N. Lophitis et al. [3]. and another one coefficient is determined by calibration to have a breakdown field of 12 MV/cm. The drift region thickness (W) is set to be 1 mm and the N-type doping concertation (Nd) is set to be 1017 /cm3. A 100 nm SiO2 passivation is employed to optimize the blocking capabilities. The 4 coefficients are applied to the model and their impact on the device performance are analyzed with the simulation. The breakdown voltages (BV) for the 4 II coefficients are 351, 355, 2090, and 527 V respectively. The discrepancy of the II coefficients also affects the electric field distribution while the breakdown fields for the 4 II coefficients are 8.8, 8.8, 43, and 12 MV/cm respectively. The distribution of the electric field in the devices shows the breakdown occurs due to EF crowding at the anode edge, however, it is alleviated by SiO2 passivation structure. [1] J. Appl. Phys. 111, 103711 (2012). [2] Semicond. Sci. Technol. 17, L59 (2002) [3] Disruptive Wide Bandgap Semiconductors, Related Technologies, and Their Applications. (2018)

EMC 2023

Effect of Impact Ionization Coefficients on High-Voltage Vertical AlN Power Devices

aln power device impact ionization coefficient
