In this work, we demonstrate a pseudomorphic Al0.87Ga0.13N/Al0.64Ga0.36N metal-oxide-semiconductor HFETs (MOSHFET) on a single crystal bulk AlN substrate with linear ohmic contacts (RC ~ 4.3 Ωmm) enabled by a 30 nm thick reverse composition (x = 87% to 40%) graded contact making AlxGa1-xN layer using MOCVD. In addition to the thermal benefits, AlN substrates allow the growth of pseudomorphic epilayer structures for extreme bandgap (EBG) AlxGa1-xN channel HEMT devices (Al-composition &gt; 60%, bandgap &gt; 4.5 eV). The measured threading dislocation densities in our pseudomorphic epilayers were &lt; 104 cm-2 which should lead to significantly lower gate-leakage thus promoting device stability.[1] These transistor devices showed Baliga Figure of Merit (BFOM) of 460 MW/cm2, which to date represents state-of-the-art performance for AlGaN-channel devices with similar composition. Device fabrication began with mesa isolation using Cl2-based ICP-RIE followed by Zr-stack metal deposition by e-beam evaporation as source/drain contacts, and rapid thermal annealing at 950 °C for 30 s under N2 environment. This was followed by an ICP-RIE etch of the graded layer from the access region, 10 nm SiO2 deposition as the gate oxide, Ni/Au gate, and Ti/Ni/Au probe pads deposition. Finally, the devices were embedded in 400 nm thick SiO2 film by PECVD to relieve the surface electric field for the breakdown voltage measurements. In addition to the bulk AlN substrates, identical devices were also fabricated where the same epilayer structure was deposited on AlN templates. These innovations enabled MOSHFET devices with on-state peak drain current density 610 mA/mm (at +2V gate bias), on-off ratio (107), a three-terminal off-state breakdown field &gt; 3.7 MV/cm, and BFOM of 460 MW/cm2. Further optimization of surface passivation and edge termination could improve the effective off-state critical breakdown field (EC) to &gt; 10 MV/cm, as measured in 2-terminal measurements by our team and others.[2,3] Deep scaling of EBG AlGaN power devices is enabled by this high EC. Compact devices have the additional advantage of reduced capacitance and other parasitics, allowing faster switching. However, the increased power density also leads to thermal limitations in overall system performance, e.g., current droop and premature failure, limiting deep-scaling of III-N power devices, due to poor heat removal through the currently used substrates with poor thermal conductivity (silicon, sapphire, Ga2O3).[4] We demonstrate using a novel thermal titration technique that the device on single crystal bulk AlN compared to identical structures on sapphire substrates shows 70% reduction in thermal impedance to 10 K-mm/W, a value that is comparable to SiC and copper heat-sinks. We will show that the improved electrical performance above is due to this enhanced thermal management from the bulk AlN substrate, arising from its intrinsic excellent thermal conductivity and high-temperature stability.[5] These advantages of EBG III-nitrides are attractive for post-GaN deep-scaled efficient and compact co-designed power electronics with passive thermal management, such as in consumer electronic chargers, and next-generation electric vehicles (EV).[6] [1] S. Rathkanthiwar, J. Houston Dycus, S. Mita, R. Kirste, J. Tweedie, R. Collazo, &amp; Z. Sitar. Applied Physics Letters, 120(20), 202105 (2022). [2] K. Hussain, A. Mamun, R. Floyd, M. D. Alam, M. E. Liao, K. Huynh, ... &amp; A. Khan. Applied Physics Express. (2023). [3] D. Khachariya, S. Mita, P. Reddy, S. Dangi, J. H. Dycus, P. Bagheri, ... &amp; S. Pavlidis. Applied Physics Letters, 120(17), 172106 (2022). [4] R. L. Xu, M. M. Rojo, S. M. Islam, A. Sood, B. Vareskic, A. Katre, ... &amp; E. Pop. Journal of Applied Physics, 126(18), 185105 (2019). [5] N. Yafune, S. Hashimoto, K. Akita, Y. Yamamoto, H. Tokuda, &amp; M. Kuzuhara. Electronics letters, 50(3), 211-212 (2014). [6] T. Kachi. Japanese Journal of Applied Physics, 53(10), 100210 (2014).

EMC 2023

Al0.64Ga0.36N Channel MOSHFET on Single Crystal Bulk AlN Substrate for Co-Designed Power Electronics

reverse grade layer

baliga figure of merit

single crystal bulk aln

The Electronic Materials Conference (EMC) is the premier annual forum on the preparation, characterization and use of electronic materials. This year’s event will feature a plenary session, topical sessions, a poster session and more.

EMC is coordinated with the Device Research Conference (DRC). This recognizes the strong interaction between device and electronic materials research and provides fruitful exchange of information between attendees of both Conferences.

The Electronic Materials Conference (EMC) is the premier annual forum on the preparation, characterization and use of electronic materials.

In this work, we demonstrate a pseudomorphic Al0.87Ga0.13N/Al0.64Ga0.36N metal-oxide-semiconductor HFETs (MOSHFET) on a single crystal bulk AlN substrate with linear ohmic contacts (RC ~ 4.3 Ωmm) enabled by a 30 nm thick reverse composition (x = 87% to 40%) graded contact making AlxGa1-xN layer using MOCVD. In addition to the thermal benefits, AlN substrates allow the growth of pseudomorphic epilayer structures for extreme bandgap (EBG) AlxGa1-xN channel HEMT devices (Al-composition > 60%, bandgap > 4.5 eV). The measured threading dislocation densities in our pseudomorphic epilayers were < 104 cm-2 which should lead to significantly lower gate-leakage thus promoting device stability.[1] These transistor devices showed Baliga Figure of Merit (BFOM) of 460 MW/cm2, which to date represents state-of-the-art performance for AlGaN-channel devices with similar composition. Device fabrication began with mesa isolation using Cl2-based ICP-RIE followed by Zr-stack metal deposition by e-beam evaporation as source/drain contacts, and rapid thermal annealing at 950 °C for 30 s under N2 environment. This was followed by an ICP-RIE etch of the graded layer from the access region, 10 nm SiO2 deposition as the gate oxide, Ni/Au gate, and Ti/Ni/Au probe pads deposition. Finally, the devices were embedded in 400 nm thick SiO2 film by PECVD to relieve the surface electric field for the breakdown voltage measurements. In addition to the bulk AlN substrates, identical devices were also fabricated where the same epilayer structure was deposited on AlN templates. These innovations enabled MOSHFET devices with on-state peak drain current density 610 mA/mm (at +2V gate bias), on-off ratio (107), a three-terminal off-state breakdown field > 3.7 MV/cm, and BFOM of 460 MW/cm2. Further optimization of surface passivation and edge termination could improve the effective off-state critical breakdown field (EC) to > 10 MV/cm, as measured in 2-terminal measurements by our team and others.[2,3] Deep scaling of EBG AlGaN power devices is enabled by this high EC. Compact devices have the additional advantage of reduced capacitance and other parasitics, allowing faster switching. However, the increased power density also leads to thermal limitations in overall system performance, e.g., current droop and premature failure, limiting deep-scaling of III-N power devices, due to poor heat removal through the currently used substrates with poor thermal conductivity (silicon, sapphire, Ga2O3).[4] We demonstrate using a novel thermal titration technique that the device on single crystal bulk AlN compared to identical structures on sapphire substrates shows 70% reduction in thermal impedance to 10 K-mm/W, a value that is comparable to SiC and copper heat-sinks. We will show that the improved electrical performance above is due to this enhanced thermal management from the bulk AlN substrate, arising from its intrinsic excellent thermal conductivity and high-temperature stability.[5] These advantages of EBG III-nitrides are attractive for post-GaN deep-scaled efficient and compact co-designed power electronics with passive thermal management, such as in consumer electronic chargers, and next-generation electric vehicles (EV).[6] [1] S. Rathkanthiwar, J. Houston Dycus, S. Mita, R. Kirste, J. Tweedie, R. Collazo, & Z. Sitar. Applied Physics Letters, 120(20), 202105 (2022). [2] K. Hussain, A. Mamun, R. Floyd, M. D. Alam, M. E. Liao, K. Huynh, ... & A. Khan. Applied Physics Express. (2023). [3] D. Khachariya, S. Mita, P. Reddy, S. Dangi, J. H. Dycus, P. Bagheri, ... & S. Pavlidis. Applied Physics Letters, 120(17), 172106 (2022). [4] R. L. Xu, M. M. Rojo, S. M. Islam, A. Sood, B. Vareskic, A. Katre, ... & E. Pop. Journal of Applied Physics, 126(18), 185105 (2019). [5] N. Yafune, S. Hashimoto, K. Akita, Y. Yamamoto, H. Tokuda, & M. Kuzuhara. Electronics letters, 50(3), 211-212 (2014). [6] T. Kachi. Japanese Journal of Applied Physics, 53(10), 100210 (2014).
