Wide bandgap GaN holds great promise for high-efficiency power conversion systems due to the excellent physical properties of GaN material. For GaN devices, vertical structure devices have attracted great attention after the lateral GaN-HEMT device since they have high current density, lower peak electric field at high voltage, and immunity to surface-related issues. GaN stability is a serious concern for predictable device behavior in real-world operations. For now, the reliability of vertical GaN devices still needs to be investigated systematically. In this work, the first comprehensive study of the reliability of GaN vertical P-I-N diode was presented. The device stability and parameter shift under high-temperature stress and current stress have been investigated. The failure mechanism of the device at high power density has been studied. For the high-temperature stress, first, the temperature of devices rising from 25 °C to 400 °C, and the forward curves of the device during temperature stress are shown in Fig.1. The extracted turn-on voltage and On-resistance are shown in Fig.2. At each temperature value, several curves were scanned in case of the transient instability at variable temperature. It shows that the turn-on voltage keeps decreasing with the temperature increase due to the energy band narrowing with increasing temperature. And the turn-on voltage can completely recover after the high-temperature stress is finished. For the On-resistance, it shows that the On-resistance decreases with the temperature increasing from 25°C to 100°C but is stable at each temperature. When the temperature is increased from 125°C to 400 °C, the On-resistance first increases and then decreases. However, the trend is not evident in this experiment. Therefore, another long-time temperature stress testing of 200°C and 400°C was done, as shown in Fig. 3 (forward curves). And the extracted On-resistance is shown in Fig. 4. For the temperature stress of 200°C, the On-resistance first decreases and then increases to larger than the original value. For the stress of 400°C, the On-resistance decreased and then was kept at a constant value. The reason that the device’s On-resistance changed during the temperature stress of 200°C is still under investigation. In addition, the On-resistance can recover from high temperatures. For the current stress testing (turn-on state), first, long-time current stress was finished. It showed that the GaN vertical P-I-N diode is very stable for long-time operation without any degradation. However, at the beginning of the stress, the device is not stable due to trapping behavior and carrier accumulation. As shown in Fig. 5, the current stress at voltages from 4V to 8V and a stress time of the 30s, 60s, 90s, and 120s were applied to a device, respectively. It shows that for the same voltage, the on-resistance (Fig. 6) will decrease to a certain value and then keep constant. This means the filling of the trapped states in the device is voltage-dependent. We also did reverse testing of the recovery of On-resistance at negative voltage stress. After the current stress process of Fig. 5, this device was applied to a negative voltage of -5 V, -10 V, -20 V, and -50 V, respectively. After each reverse voltage stress, the process in Fig. 5 was repeated, as shown in Fig. 7. It was shown that the On-resistance of the device shows voltage level dependent character again after -50 V stress, indicating that the trap and carrier accumulation can be recovered at a higher negative voltage. Fig. 8 shows the turn-on voltage of the device with different voltage and time stress. The shift of the turn-on voltage is smaller than 0.05 V, indicating that the GaN vertical P-I-N diode has good reliability of turn-on voltage. Fig. 9 shows the forward curve after high power density stress. The failure mechanism is still under investigation.

EMC 2023

Reliability Study and Analysis of Vertical GaN Power Devices

gan reliability

device test
