Transparent conductive oxides (TCOs) are essential elements for photovoltaics and optoelectronic devices. In this work thin films of ZnO co-doped with In3+ and Ga3+ (IGZO) were deposited by atomic layer deposition onto various commercial and homegrown substrates to develop TCOs and characterized by X-ray diffraction, scanning electron microscopy, transmission electron microscopy, atomic force microscopy, optical spectroscopy, and Hall-effect measurements. The thin films exhibit structural stability, remarkable conductivity at room temperature, high visible range transparency, and a band gap near 3.42 eV. Optical and electrical characterization revealed a TCO figure of merit Φ = 8.66 × 10-2 Ω-3 for IGZO with a thickness of 164 nm surpassing Al-doped ZnO (AZO) TCOs and rivalling the industry standard ITO. Temperature-dependent electrical transport measurements of IGZO films revealed a fully degenerate semiconductor behavior.

EMC 2023

Atomic Layer Deposition of Highly Conductive Highly Transparent Indium Gallium Doped Zinc Oxide Thin Films
