We simulate saturation drain current changes during hot-carrier degradation (HCD) in dynamically-doped (D2) and planar CMOS FETs of a similar architecture. To achieve this, we use our HCD model validated against experimental data over a broad class of transistors. These simulations show that at Vgs ≤ 0.9V (covering the operating regime) D2 FETs have superior reliability, while at Vgs ≥ 1.0V the CMOSFET begins to be more reliable. Under these stress voltages, HCD is governed by the multiple-carrier process of bond dissociation controlled by the carrier concentration (rather than energy), which has different Vgs dependences in D2 and CMOS FETs.

IRPS 2022 Main Conference

On Superior Hot Carrier Robustness of Dynamically-Doped Field-Effect-Transistors

carrier transport

dynamically doped field-effect-transistor

hot-carrier degradation

interface traps
