We extend our framework for hot-carrier degradation (HCD) modeling by covering the impact of self-heating (SH), which has three main aspects: (i) perturbation of carrier transport, (ii) acceleration of the thermal contribution to bond breakage, and (iii) and shortening vibrational lifetime of the bond, i.e. reducing the multiple-carrier mechanism rate. We validate the framework against HCD data acquired in nFinFETs and pNWFETs under various stress conditions, analyze the importance of each of the aforementioned aspects, and explain why in n-channel FETs SH slightly inhibits HCD, while in p-channel devices HCD is accelerated by SH.

IRPS 2022 Main Conference

Understanding and Modeling Opposite Impacts of Self-Heating on Hot-Carrier Degradation in n- and p-channel Transistors

nanowire fet

lattice heat flow equation

carrier transport

hot-carrier degradation

self-heating

finfet

modeling
