Benefitting from forksheet device co-integration with nanosheets, we evaluate the reliability concerns that come along the use of the SiN-based dielectric wall. This wall could act as a “sponge” for non-equilibrium charges during hot-carrier stress, or absorb charges resulting from the horizontal field between n- and p-type devices. In-depth analysis showed no significant charge trapping phenomena were caused by the presence of the SiN wall. Both BTI and—after accounting for processing imperfections—HCI reliability were found to be comparable. We conclude the SiN dielectric wall does not constitute an additional reliability concern for the novel FSH architecture.

IRPS 2022 Main Conference

Evaluating Forksheet FET reliability concerns by experimental comparison with co-integrated Nanosheets
