It is well-known that power devices used in high-energy physics and space applications are often subjected to high amounts of radiation. Therefore, it is essential to accurately predict the long-term degradation of these power devices in the presence of radiation. In this paper, we expose LDMOS transistors to various TID of gamma radiation, quantify the dose-dependent generation of interface traps and trapped charges using a novel charge pumping technique; and establish the universality of the degradation kinetics, and illustrate that the model and inferences drawn from the findings in this paper can be applied to other LDMOS devices as well.


IRPS 2022 Main Conference

Correlated Effects of Radiation and Hot Carrier Degradation on the Performance of LDMOS Transistors
