In this paper, a simple circuit is incorporated in a 650V E-mode GaN HEMT process technology to protect all terminals against ESD stress from any direction. Even in the worst case, the gate subjected to negative ESD pulse with respect to grounded drain, the 650V E-mode HEMT can still pass 5kV HBM.

IRPS 2022 Main Conference

Incorporation of a Simple ESD Circuit in a 650V E-Mode GaN HEMT for All-Terminal ESD Protection
