Manipulating magnetization of ferromagnetic material with small amount of energy is of contemporary interest in field of Spintronics.There are various ways in which manipulation of magnetization can be done such as,1) Using spin polarized current [1] 2) Electric field controlled [2] 3) SAW based technique [3],4) Heat current controlled [4],among all currently available techniques Electric Field controlled is ultra-low power [5].All the effects in nature also have a reciprocal effect based on the Onsager reciprocity e.g. the inverse of spin transfer torque effect viz. spin pumping can be used for converting magnetization oscillations into spin current.Here we have experimentally demonstrated the Inverse of VCMA effect by which magnetization oscillations produce charge voltage. To demonstrate the inverse-VCMA effect [6],we fabricated a two port device as shown schematically in Fig.1 We deposited stack on Si/SiO2 substrate: Ta(5)/Ru(5)/Ta(5)/Ru(5)/Ta(9)/COFEB(1)/CoFe(0.2)/Ir(0.1)/MgO(2.4)/Ta(5)/Ru(7). We then fabricated tunnel junctions of dimension 3umx80um with contacts. A CPW was fabricated on the top,which was electrically insulated from the bottom pillar. The patterning of the device was done by e-beam lithography and Ar-ion milling. We measured the S-parameters of the device using a (VNA). The magnetic field was swept along different directions by varying θ and φ. The measurement of S21 signal corresponds to the direct VCMA effect.Applying signal to port 1 oscillates magnetization of FM by the VCMA effect and signal is induced in the port 2 by induction.The measurement of S12 corresponds to the inverse of VCMA effect as shown in Fig.2. On applying oscillating voltage to port 2,creates oscillating field on the FM.The oscillation of the magnetization of the FM induces voltage in the port 1 by the inverse-VCMA effect.Both the S12 &amp; S21 signal are largest at the FMR frequency.We observed that the Onsager reciprocity relation S12(B)=S21(-B) is satisfied.The angular dependence of the S-parameters confirmed that the signals arise from inverse VCMA effect. We would like to thank IIT Bombay NanoFabrication facility for supportReferences: [1] J.C.Slonczewski JMMM volume 159, Issues 1–2 (1996). [2] T. Maruyama, et.al., Nat. Nanotechnology. 2008, 406(2009). [3] Swapnil Bhuktare et.al., Appl. Phys.Lett. 114, 052402 (2019). [4] Arnab Bose et.al, PhysRevB.98.184412 (2018). [5] T. Nozaki et.al., Nat. Physics. 2298 (2012). [6] Ambika Shanker Shukla et.al. Science Advances (accepted) 2020.

MMM 2020

Inverse of Voltage Controlled Magnetic Anisotropy (VCMA) effect

The 15th Joint MMM-INTERMAG Conference (2022 Joint) is sponsored jointly by AIP Publishing and the IEEE Magnetics Society. Members of the international scientific and engineering communities interested in recent developments in fundamental and applied magnetism are invited to attend and contribute to the technical sessions. The technical program will include invited and contributed papers in oral and poster sessions, invited symposia, a plenary session, and an evening session, with about 1500 presentations overall. This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

The 2022 Joint Conference will offer both in-person and prerecorded on-demand content.

For tickets to the event, please register at the following link: https://magnetism.org/register

Please register for the Joint MMM-Intermag conference to join the event.

2022 Joint MMM-INTERMAG

This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

Manipulating magnetization of ferromagnetic material with small amount of energy is of contemporary interest in field of Spintronics.There are various ways in which manipulation of magnetization can be done such as,1) Using spin polarized current [1] 2) Electric field controlled [2] 3) SAW based technique [3],4) Heat current controlled [4],among all currently available techniques Electric Field controlled is ultra-low power [5].All the effects in nature also have a reciprocal effect based on the Onsager reciprocity e.g. the inverse of spin transfer torque effect viz. spin pumping can be used for converting magnetization oscillations into spin current.Here we have experimentally demonstrated the Inverse of VCMA effect by which magnetization oscillations produce charge voltage. To demonstrate the inverse-VCMA effect [6],we fabricated a two port device as shown schematically in Fig.1 We deposited stack on Si/SiO2 substrate: Ta(5)/Ru(5)/Ta(5)/Ru(5)/Ta(9)/COFEB(1)/CoFe(0.2)/Ir(0.1)/MgO(2.4)/Ta(5)/Ru(7). We then fabricated tunnel junctions of dimension 3umx80um with contacts. A CPW was fabricated on the top,which was electrically insulated from the bottom pillar. The patterning of the device was done by e-beam lithography and Ar-ion milling. We measured the S-parameters of the device using a (VNA). The magnetic field was swept along different directions by varying θ and φ. The measurement of S21 signal corresponds to the direct VCMA effect.Applying signal to port 1 oscillates magnetization of FM by the VCMA effect and signal is induced in the port 2 by induction.The measurement of S12 corresponds to the inverse of VCMA effect as shown in Fig.2. On applying oscillating voltage to port 2,creates oscillating field on the FM.The oscillation of the magnetization of the FM induces voltage in the port 1 by the inverse-VCMA effect.Both the S12 & S21 signal are largest at the FMR frequency.We observed that the Onsager reciprocity relation S12(B)=S21(-B) is satisfied.The angular dependence of the S-parameters confirmed that the signals arise from inverse VCMA effect. We would like to thank IIT Bombay NanoFabrication facility for supportReferences: [1] J.C.Slonczewski JMMM volume 159, Issues 1–2 (1996). [2] T. Maruyama, et.al., Nat. Nanotechnology. 2008, 406(2009). [3] Swapnil Bhuktare et.al., Appl. Phys.Lett. 114, 052402 (2019). [4] Arnab Bose et.al, PhysRevB.98.184412 (2018). [5] T. Nozaki et.al., Nat. Physics. 2298 (2012). [6] Ambika Shanker Shukla et.al. Science Advances (accepted) 2020.
