Enhancement of switching perpendicular magnetic tunnel junctions (p-MTJs) with an electric-field has been a milestone for realizing ultra-low energy memory and computing devices. To integrate with current STT-MTJ and SOT-MTJ devices the typical linear fJ/Vm range voltage controlled magnetic anisotropy (VCMA) needs to be enhanced through stack engineering. We have investigated possible non-linear voltage controlled magnetic anisotropy (VCMA) in heavily electron depleted devices, where the magnetic anisotropy could be reduced with positive and negative voltages, differing with the typical linear VCMA voltage behavior. A possible bidirectional and 1.1 pJ/Vm VCMA effect can be realized based on theoretical predictions with heavily electron depleted Fe/MgO interfaces. To improve upon existing VCMA technology we have proposed inserting high work function materials under the magnetic layer which will deplete electrons from the magnetic layer biasing the gating window into the electron-depleted regime where the pJ/Vm and bidirectional VCMA effect was predicted. We have demonstrated tunable control of the under-layer’s work function by utilizing Ta/Pd(x)/Ta trilayers. By modulating the Pd thickness from 0-20 nm we have observed a tunable change in the Ta layer’s work function from 4.3eV to 4.8eV. To investigate the extent of the electron depletion as a function of the Pd thickness in the trilayer we have performed DFT calculations on supercells of Ta/Pd (X)/Ta /CoFe /MgO. We are working to improve the quality of our gate dielectric materials to avoid hysteretic ionic effects allowing for a reliable VCMA measurement of the Ta/Pd/Ta samples.

![](https://assets.underline.io/uploads/markdown_image/1/image/a8360ad2cb5f5ae617004083260b5005.jpg)

Enhancement of Voltage Controlled Magnetic Anisotropy (VCMA) Through Electron Depletion

2022 Joint MMM-INTERMAG

Enhancement of Voltage Controlled Magnetic Anisotropy (VCMA) Through Electron Depletion

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

INTERMAG 2021

poster

The 15th Joint MMM-INTERMAG Conference (2022 Joint) is sponsored jointly by AIP Publishing and the IEEE Magnetics Society. Members of the international scientific and engineering communities interested in recent developments in fundamental and applied magnetism are invited to attend and contribute to the technical sessions. The technical program will include invited and contributed papers in oral and poster sessions, invited symposia, a plenary session, and an evening session, with about 1500 presentations overall. This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

The 2022 Joint Conference will offer both in-person and prerecorded on-demand content.

For tickets to the event, please register at the following link: https://magnetism.org/register

Please register for the Joint MMM-Intermag conference to join the event.

This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

MRAM is a non-volatile memory technology that stores a bit as a magnetic state of a ferromagnetic CoFeB free layer which either aligns or anti-aligns with a fixed CoFeB layer, where these two layers sandwich a non-magnetic MgO layer, shown in fig.1a. The modern market is predominantly dynamic and static RAM which are both volatile which requires large amounts of power in high peformance clusters. MRAM is ultrafast and durable while scaling to volumes smaller than the limitations of SRAM and DRAM, attracting significant research and development.[1]To achieve practical applications, MRAM must display high thermal stability, a high tunnel magnetoresistance ratio and a low writing current at competing volumes. A recent development with potential to achieve this scalability is to use tower structures with height greater than the diameter, which allows the perpendicular shape anisotropy and the interfacial perpendicular magnetic anisotropy to favour out-of-plane magnetisation.[2]For reliable MRAM, the switching mechanism at operational temperatures needs to be understood. This study uses atomistic simulations which model the tower structure with varied free layer thicknesses using two anti-ferromagnetically coupled CoPt layers to pin the fixed layer, with a monolayer either side of the MgO with enhanced exchange coupling and uniaxial anisotropy. The system is modelled using a spin Hamiltonian with thermal fluctuations and dipole fields included with the LLG.[3]We have found in fig.1b(i) that the susceptibility of the free layer varies hugely as the volume is increased, but dividing these taller towers into smaller local regions in fig. 1b(ii) we find smaller and correlated curves. This shows the magnetisation is non-uniform throughout the tower, which may suggest a non-uniform magnetisation mode. In fig. 1c(i) we see snapshots of the reversal process at 50K demonstrating nucleated domain wall reversal mode in taller towers, while fig.1c(ii) shows the switching is coherent for smaller towers.

![](https://assets.underline.io/uploads/markdown_image/1/image/3dbfeaa4ddcc03812f89632cb15415c0.jpg)

Figure 1 a) The structure of the PSA MRAM b) i) The susceptibility for the whole free layer ii) The susceptibility of 10nm parts of the 48nm tower c) i) Nucleated reversal in the 48nm tower ii) Coherent rotation in the 10nm tower

Atomistic Study of the Thermodynamic Properties and Switching Dynamics of Perpendicular Shape Anisotropy MRAM

Neuromorphic computing is attracting the attention of researchers for its usefulness in ultra-low-power computing applications1. Among the several magnetic and non-magnetic candidates to achieve low-power neuron and synaptic devices, the domain wall magnetic tunnel junctions (DW-MTJ) are the most promising contenders for energy efficiency. However, to realize the synaptic functions in neuromorphic devices, one must achieve multi-resistance states. The pinning sites can aid in achieving the required multi-resistance states2. Therefore, we propose meander DW devices, where segments of DW-MTJ wires join at an offset, which alters the energy landscape locally and helps in achieving deterministic DW motion. To study the proposed concept, we optimized the DW-MTJ stack with the perpendicular magnetic anisotropy to achieve a higher tunnel magnetoresistance (TMR) of 169% and a high RA (resistance-area product) of 241 Wmm2 suitable for DW devices with a large area. Subsequently, we measured the magnetic hysteresis (M-H) loops of the thin films to observe the layer-wise switching along with magnetic field variation (fig. 1 (a)). We have also measured the minor loop (fig. 1 (b)) and found that the coercivity of the free layer is ~21 Oe, which is suitable for energy-efficient DW motion. Next, we optimized the fabrication process for 3-terminal synaptic devices (fig. 1 (c)). We fabricated a sequence of devices with a DW-MTJ wire width w = 10 mm and corresponding offset (d) values ranging from 40% (of w) to 70% in the steps of 10%. Further, we fabricated three types of devices for every offset; (i) constant offset, increase in offset by (ii) 5%, and (iii) 10% over successive pinning sites. Finally, we performed field and current-driven DW motion experiments and witnessed the synaptic functions. Here we present the results of field-driven DW motion in fig. 1 (d). The stack details, process insights, and experimental findings will be presented in detail during the conference.

![](https://assets.underline.io/uploads/markdown_image/1/image/5676d1e7a6f58421533aa347a7748345.jpg)

Figure. (a) M-H loop of the full stack, (b) minor loop illustrating the switching of the free layer, (d) micrograph of the 3-terminal synaptic device, and (e) read-out TMR signal of field driven-DW motion.

Terminal Domain Wall Device Based Synapses for Neuromorphic Computing

Encoding information in thin films with perpendicular magnetic anisotropy (PMA) holds promise for the next generation of data storage and logic operation applications [1]. Thin films with a large coercivity provide high stability of the encoded information but cause a high energy cost of writing data [2]. Therefore, reducing coercivity while writing data is a practical method to decrease the energy cost. Here, we experimentally demonstrated the control of coercivity in a PMA film using surface acoustic waves (SAWs), which can introduce oscillating strain waves in the thin films over millimetric distances. Two interdigitated transducers (IDTs, Fig.1a), whose centre frequency is 93.35 MHz (Fig. 1b), were patterned on opposite ends of a 2-mm-wide stripe of Ta(5.0 nm)/Pt(2.5 nm)/Co(1.1 nm)/Ir(1.5 nm)/Ta(5.0 nm) film. The film was dc magnetron sputtered onto a lithium niobate (LiNbO3) substrate, which supports the SAW propagation. A wide-field Kerr microscope was used to measure the hysteresis loops of the film with SAW both on and off at room temperature. Results showed that the coercivity of the thin films without SAW is 4.93±0.06 mT (Fig. 2a). Owing to the magnetoelastic coupling effect [3,4], the standing SAWs locally reduce the anisotropy and thus the thin film coercivity, which can be controlled by the applied SAW power. Coercivity reduction, which is enhanced by increasing the SAW power, can be up to about 18% for an input SAW power of 28 dBm (4.04±0.09 mT, Fig. 2b). Coercivity reduction only occurs at the centre frequency (Fig. 2c), which rules out the effect of a rising temperature that a SAW potentially can cause. This study indicates the possibility of remote and energy-efficient control of magnetization switching.

![](https://assets.underline.io/uploads/markdown_image/1/image/7651ddbabe3b6a643e873d0705d1cff0.jpg)

Fig.1 (a) Diagram of experimental setting-up. Interdigitated transducers (IDTs) were patterned by the side of the Ta(5.0)/Pt(2.5)/Co(1.1)/Ir(1.5)/Ta(5.0) film (thickness in nm). Hysteresis loops were taken by a Kerr microscope. (b) S-parameters of the IDTs (centre frequency of 93.35 MHz).

![](https://assets.underline.io/uploads/markdown_image/1/image/3e15320f4d7d218cf345ab83929d079e.jpg)

Fig. 2 (a) Hysteresis loops and (b) coercivity of the thin film under various surface acoustic waves (SAW) power (23 to 28 dBm) at 93.35 MHz. (c) Coercivity of the thin films under various frequency at 28 dBm.

Coercivity control of thin films with perpendicular magnetic anisotropy by surface acoustic waves

As a promising non-volatile memory, Spin Transfer Torque Magnetic Random Access Memory (STT-MRAM) suffers from high error rate due to stochastic switch [1]. Some papers use Error Correcting Code (ECC) with powerful error correction capabilities to suppress high error rate, which lead to high delays and high check bit consumption. According to published reports, the error occurring of STT-MRAM is a serious asymmetry phenomenon [2]. The write error rate of 0 → 1 is much higher than that of 1 → 0 since 0 → 1 transition requires higher energy to ensure reliably commute the value. The traditional ECC approaches for other kinds of memories are designed for symmetric error correcting, which are not suitable for STT-MRAM. A weighted error correction mechanism is proposed and fulfilled in the paper, which can be used for the asymmetric error situation. Firstly, the codewords are weighed by estimating the different probabilities of error in state 0 and 1. In STT-MRAM, the error occurrence rate on state 0 is much higher than that on state 1. Through the check matrix, the words can be preliminarily judged to determine which bits may be wrong. Through the different weights of data 0 and 1, a bit with the highest error probability can be calculated. Then this bit is flipped to get a new codeword, which is substituted into the check matrix again to get a new error situation. The process of WECC is shown in Fig.1. If situation improves, the new codeword can be kept. Otherwise, the previous substitution operation is cancelled. In order to ensure the effectiveness of the error correction mechanism, the assistance of other ECCs such as BCH or LDPC is usually required. The error correction mechanism proposed in the paper can effectively reduce the error correction delay and decrease the check bit consumption. A virtual system in GEM5 is built up to evaluate the proposed WECC mechanism. The simulation results are used for the analysis of the error correction algorithm, showing the effectiveness of the WECC proposed in the paper for STT-MRAM.

![](https://assets.underline.io/uploads/markdown_image/1/image/fa6a1883b97a9ef7b919f61da0895f72.jpg)

Fig.1 Process of WECC

Weighted Error Correcting Code (WECC) against Asymmetric Error of STT-MRAM

Spin transfer torque[1] is an important phenomenon in order to develop of non-volatile magnetic memory. Using this spin transfer torque principle, it was predicted[2] and experimentally confirmed[3] that a voltage could be generated in the magnetic nanostructure. This effect is called spin motive force and is expected for next-generation power sources. It is not clear how the Faraday electromotive force[4] can be separated from the spin motive force, and there are few studies reported and the spin motive force in µV class. It is very small. To greatly increase the value, we fabricated Gd21(Fe75Co25)79 magnetic wire and succeeded in generating a spin motive force by domain wall motion. We prepared the following film stacks using rf and dc magnetron sputtering: Gd21 (Fe75Co25)79 (20)/SiN (10), the films are grown at the room temperature. The magnetic wires (3 µm wide and 125 µm long) and Hall crosses were micro-fabricated by an Electron-beam lithography (EBL) system and a lift-off method. Next, we prepared two types of samples, a sample with injection of domain wall and a sample without injection of domain wall. A magnetic field was applied to the sample, and the generated voltage was observed by an oscilloscope through a 100x amplifier. Spin motive force is determined by subtracting the induced electromotive force generated in the sample without injection of domain wall. Figure 1 (a) shows the spin motive force measurement system. Figure 1 (b) shows the value of the spin electromotive force by subtracting the induced electromotive force. As a result, a huge spin motive force of 12 mV was obtained. This is financially supported by KAKENHI 918023,918055,918043.

![](https://assets.underline.io/uploads/markdown_image/1/image/36414d6f67eeb09c3efa72deacf02c73.jpg)

![](https://assets.underline.io/uploads/markdown_image/1/image/f9d644bd049228bbbc961dd9398e36c1.jpg)

Milli volt class spin motive force due to domain wall motion in GdFeCo magnetic wire

Milli volt class spin motive force due to domain wall motion in GdFeCo magnetic wire

Spin transfer torque (STT) magnetic RAM (MRAM) is one of the promising emerging memory technologies, which combines endurance, speed and energy efficiency of SRAM and DRAM with non-volatility of flash [1]. However, the write speed and write power consumption is a major challenge for the establishment of STT-based storage devices in universal memory [2]. In the paper, the Early Write Termination (EWT) technology combined with the pipeline architecture is co-designed for the STT-MRAM to improve the write efficiency. In the traditional write operation, the original stored data is directly overwritten by the new data, without concerning on whether the new data is the same as the original data or not. There exists unnecessary operation if the written data is the same as the stored ones, which leads to the write power consumption. To avoid the unnecessary write operation, a pre-charge sense amplifier is used to sense the stored data in advance. Only the new data is allowed to be written into the memory cell when the new data is different from the stored data. Moreover, considering the delay of the additional circuits, the pipeline architecture is also applied on the STT-MRAM. Several latches operating in response to a clock signal to process the data by dividing the write operation into a plurality of stages and carrying out them in pipelining manner [3]. Pipeline technology can process multiple instructions in parallel, greatly increasing the average write speed. The proposed write strategy of STT-MRAM achieves better write efficiency and lower power consumption, which has potential application in STT-MRAM in the future.

![](https://assets.underline.io/uploads/markdown_image/1/image/f0a4a9c940c5ec9c080f178a3a404143.jpg)

![](https://assets.underline.io/uploads/markdown_image/1/image/1b90046cd006ea471df66745127b56fd.jpg)

The fast write strategy of STT-MRAM with pipeline architecture

The fast write strategy of STT-MRAM with pipeline architecture

Unlike traditional memories such as SRAM and DRAM, STT-MRAM has many advantages, especially non-volatility, which has attracted the attention of many researchers in recent years. Nowadays, MRAM is one of the most competitive candidates for next-generation memory. However, spintronic devices require large switching current to achieve fast switching speed, which leads to more power consumption and heat fluxes of MRAM. Power budget and thermal issues limit the 3D stacking of MRAM. Therefore, it is necessary to establish a thermal model of the power-related 3D stacked MRAM in the early stage of design. Since in the duality between thermal and electrical phenomena [1], heat flow is analogous to current, temperature is analogous to voltage, thermal conductance is analogous to electrical conductance, and thermal capacity is analogous to electrical capacitance, a RC thermal model can be established, which can avoid using computationally intensive and time-consuming detailed finite-element model [2]. Because 3D stacked MRAM faces cooling problems, it is not only necessary to consider the circuit-level memory layer when analyzing the thermal behavior, but also to take the heat sink responsible for heat dissipation into consideration from the perspective of package level and model together. The content of this paper is organized as follows. Section I is the introduction,which introduces 3D stacking technology and puts forward the thermal issues of 3D memory. Section II presents various thermal modeling approaches. Section III proposes a power and thermal model for 3D-stacked MRAM as shown in Fig. 1, which also including the simplified memory circuit. In Section IV, the effects of the number of stacked layers, the size of dies, power density, and heat dissipation capacity on temperature are evaluated based on the established RC thermal model. Section IV shows the conclusions. It is demonstrated that this model facilitates the communication between the circuit designer responsible for power consumption and the package designer responsible for heat dissipation in the early stage of MRAM design.

![](https://assets.underline.io/uploads/markdown_image/1/image/c2c6a421afbb60a422fb189be0aae3db.jpg)

A RC Thermal Model of 3D-Stacked Stand-alone MRAM

A RC Thermal Model of 3D-Stacked Stand-alone MRAM

Current-induced domain wall motion (CIDWM) shows the promising prospect in low-power, high-density, and high-speed circuits application. Recent researches have demonstrated that the MTJ device based on CIDWM has great potential in mimicking a non-volatile artificial neuron and synapse [1, 2]. However, low speed and high-power consumption limit the further development of traditional CIDWM driven by spin transfer torque (STT). By combining the high-speed, low-power advantages of spin orbit torque (SOT) MTJ and the ability of interfacial Dzyaloshinskii–Moriya interaction (DMI) to stabilize the Néel–type domain wall, SOT and DMI-based domain wall (DW) MTJ can achieve low threshold current and high propagation speed. Currently, the corresponding device model is highly required for the circuit design in the field of the artificial neuron and synapse simulation. In the paper, a compact model for CIDWM-MTJ based on SOT and DMI is presented. It integrates SOT mechanism for magnetization reversal and domain wall nucleation, CIDWM behaviors, and tunnel resistance theory of MTJ nanopillar. The micromagnetic simulation and the temporal evolution of the DW position is carried out by solving the LLG equation. Finally, a hybrid MTJ/CMOS circuit is simulated to verify the developed model. The presented model combines the CIDWM dynamics and MTJ magnetic dynamics, showing potential application for the simulation of all-spin artificial neural network. Fig. 1 shows the three terminal device structure for SOT and DMI-based CIDWM-MTJ. Iwrite flows between T2 and T3, generating SOT. DW position in the free layer (FL) is propagated by the SOT and the DMI at the HM/FL interface.

![](https://assets.underline.io/uploads/markdown_image/1/image/aa878dc9bb9464796500bbee572ec33b.jpg)

Fig. 1 Three terminal device structure for SOT and DMI-based CIDWM-MTJ.

Compact Model of Domain Wall MTJ Device Driven by Spin Orbit Torque and Dzyaloshinskii–Moriya Interaction

Spin torque switching mechanisms and switching speed of perpendicular magnetic tunnel junctions(pMTJs) free layers are of significant interest for industrial applications and understand the fundamental physics of magnetic material’s response to a spin-polarized voltage across it. A voltage pulse, with an amplitude above the critical voltage Vc0[1], is applied across the junction to switch the magnetization of the pMTJ free layer. The pulse width must be long enough for guaranteed switching and short enough to avoid unnecessary energy consumption and unwanted heating. We have simulated zero-temperature domain wall mediated spin-torque switching of disk-shaped pMTJs with CoFeB free layer[2] to study the optimum pulse width for successful spin-torque switching. Our data show that 1) below a minimum pulse width(tmin), spin-torque switching does not occur, 2) above a maximum pulse width(tmax) switching is deterministic, and 3) for tmin&lt;tpulse&lt;tmax, final magnetization state depends on the pulse width (see Figure 1). Previous research has shown that the domain wall structure and position at the beginning of simulation affect the switching dynamics and the final magnetization state[3]. Since the exchange interaction sets the magnetic structure of the domain wall, we varied the exchange interaction strength to investigate its effect on the final magnetization state. Our results confirm that exchange interaction impacts the pulse width required for switching (Figure 2). We will present our results on the effect of the exchange constant of the free layer on pulse width required for switching and discuss the implications of such effects in pMTJ devices.

![](https://assets.underline.io/uploads/markdown_image/1/image/508e7d1271f47716bb6d7de92f1feb71.jpg)

Figure 1: Time evolution of spatially averaged magnetization along the axis perpendicular to a 30nm pMTJ disk when applied pulse voltage is 1.6Vc0. Blue(red) represent (un)successful switching.

![](https://assets.underline.io/uploads/markdown_image/1/image/78ffc3ac1f2d1e61ffbe30330dcfd426.jpg)

Figure 2: The free layer exchange constant and pulse duration(tpulse) determine the final magnetization state of the junction. When exchange interaction is weaker, longer pulses are needed for switching. Blue(red) represent (un)successful switching.

Nontrivial Relationship Between Current Pulse Width and Spin Torque Switching of Perpendicular Magnetic Tunnel Junctions

We have designed hybrid memory for magnetic random-access memory (MRAM) cells, consisting of low Curie temperature (Tc) CoPd/Pd multilayers (ML) and high Tc Co/Pd ML, and confirmed the thermally-assisted (TA) spin-transfer-torque (STT) switching [1-3]. In this study, we fabricated samples with different high Tc Co/Pd interface layer as [Co(x) /Pd(1.6-x)]1 ML / [CoPd/ Pd]2 ML (x = 0.4, 0.6, 0.8 nm), and investigated the temperature dependence of intrinsic critical current density Jc0 and thermal stability factor Δ. We also measured the magnetization dynamics of the hybrid memory layer by using the time-resolved magneto-optical Kerr effect (TRMOKE), and discussed the effect of the high TC interface layer on TA-STT switching. Current-perpendicular-to-plane type giant magneto-resistance (CPP-GMR) structures with the hybrid memory and Co/Pt reference layers were fabricated to investigate Jc0 and Δ, which are estimated from the pulse width dependence of the STT switching current density. The samples without a reference layer were also fabricated to estimate the damping constant α of the hybrid memory layer by the TRMOKE measurements. Figure 1 shows the temperature dependence of Jc0 of the hybrid memory layer with various of Co thickness x in the interface high TC layer. Jc0 decreased by elevating the temperature, and Jc0 of x = 0.8 drastically decreased compared to the other samples. Figure 2 shows the dependence of α on the Co thickness of the high TC layer. α of hybrid layers decreased with increasing x, and a drastic decrease was confirmed when x &gt; 0.6 nm. The decrease of α suggests the increase of exchange coupling between high Tc and low Tc MLs. The exchange coupling between high Tc and low Tc MLs is considered to have significant influence on the Jc0 at room temperature and its temperature dependence as shown in Fig. 1. MuMax3 simulation also supports the increase of Jc0 by reducing the exchange coupling between high Tc and low Tc MLs, which will be discussed in the presentation.

![](https://assets.underline.io/uploads/markdown_image/1/image/94ec25d1aa1e302edbac1b1c56b558b5.jpg)

Fig. 1 Temperature dependence of Jc0 of the hybrid memory layer of [Co(x)/Pd(1.6-x)]1 / [CoPd/Pd]2.

![](https://assets.underline.io/uploads/markdown_image/1/image/dfa4b70bda8ecc400ddff06cd2c2bfe4.jpg)

Fig. 2 Dependence of damping constant α of the hybrid memory layer on the thickness of Co x in high TC Co/Pd layer.
