In applications that utilize films of nanoparticles, there is a need to develop methods to fabricate stable thick films to improve materials for energy storage, sensing, or flexible electronics. [1-3]. This work seeks to increase film thickness and stability by increasing film-substrate interactions by functionalizing conductive substrates with various chelating agents. These nanoparticles are deposited via electrophoretic deposition (EPD), a method that deposits charged particles in colloidal suspensions via electrophoresis. Here, we will demonstrate the efficacy of this approach by depositing iron oxide nanoparticles onto conductive substrates functionalized with three chelating agents with different functional moieties and therefore differing chelating strengths [4]. We show that increasing chelating strength can increase film-substrate interactions, resulting in thicker films when compared to traditional EPD. Results will also be presented on how the effect of the chelating strength relates to film formation as a function of deposition conditions. Yield for EPD is influenced by deposition conditions including applied electric field, particle concentration, and deposition time. Substrates functionalized with chelating agents were used with three different sets of deposition parameters, varying the applied electric field and particle concentration. This work shows that the functionalization of substrates with chelating agents that coordinate strongly with nanoparticles used for deposition overcome parameters that traditionally hinder the deposition of thicker and more stable films. Further, films that suffer instability and low quality from high applied electric field and high particle concentration were more stable when deposited on substrates functionalized with phosphonic acid and dopamine.References: [1] C. Mahender, T. Sumangala, R. Ade, Ceram. Int., Vol. 45, p. 4316-4321 (2019) [2] E. Cao, Z. Chu, H. Wang, Ceram. Int., Vol. 44, p. 7180-7185 (2018) [3] L. Ming, H. Yang, W. Zhang, J. Mater. Chem., Vol. 2, p. 4566-4573 (2014) [4] A. Walter, A. Garofalo, A. Parat, Nanotechnol. Rev., Vol. 4, p. 581-593 (2015)

MMM 2020

Fabrication of Thick and Stable Nanoparticle Films via Electrophoretic Deposition on Substrates Functionalized with Chelating Agents
