We use focused ion beams to create specific defects on suspended 2D materials (graphene, MoS2, WSe2). We study the extent to which the defects act as nucleation sites for Au, and tune deposition conditions and surface cleanliness to facilitate self-assembly of specific nanoisland shapes.

EIPBN 2021

Focused Ion Beam Patterning for Defect-Mediated Nucleation on 2D van der Waals Materials

nucleation

defect engineering

2d materials

focused ion beam

transmission electron microscopy
