After an introduction to the npSCOPE instrument and its capabilities we will introduce the new STIM detector and present first results obtained with it on single and polycrystalline samples as well biological specimen. The latter will focus on different kinds of nanoparticle samples relevant in the field of nano-toxicology.

EIPBN 2021

 Scanning Transmission Ion Micrsocopy in the Helium Ion Microscope for nanoparticle research

channeling

helium ion microscopy

focused ion beam

sims

nanoparticles
