In this study, we investigated whether UV-cured resin thin films modified by atomic layer deposition (ALD) could be removed completely by dry etching procedures. UV-nanoimprinted deposition masks were removed completely by sequential physical and chemical dry etching procedures, to demonstrate and area selective deposition of aluminum oxide.

EIPBN 2021

Nanoimprinted Deposition Masks for Area Selective Atomic Layer Deposition of Aluminum Oxide

uv-nanoimprinting

atomic layer deposition

area selective deposition
