P. Moens, et al. have proposed that CVS-TDDB cannot capture the impact of both electron and hole trapping mechanisms on the failure distribution function, in contrast to CCS-QBD. In this work, the investigation of electron trapping under the CCS is conducted in commercial Silicon dioxides thermally grown on 4H-SiC based on the electron trapping model proposed by M. Liang, et al. The model results are consistent with the measured results when the electron trapping dominants.

IRPS 2024 Main Conference

Investigation of the Electron Trapping in Commercial Thick Silicon Dioxides Thermally Grown on 4H-SiC Under the Constant Current Stress
