A new thermal model for GaN/GaAs FETs has been developed that provides temperature estimates of individual gate fingers. The model assists in simulating scaled transistor performance and aging quickly and accurately. It provides designers with more flexibility as thermal resistance is automatically adjusted with gate periphery and gate-to-gate spacing, including non-uniform spacing.

IRPS 2024 Main Conference

Fast, Scalable, and Highly Accurate Thermal Modeling for Use in GaN/GaAs RF Circuit Modeling Platforms
