The reliability issues of the In-3D-NAND approximate searching system for Hamming distance computing are evaluated and solved by optimized high VT level, recovery healing process, and reliability tracking array. The chip with optimized high Vt level can pass the commercial 3D-NAND retention criteria. Recovery healing can mitigate over-program issue in high data update situations. Tracking array enables sensing level calibration for long-term operations. The chip provides reliable in-memory database processing function suitable for neuromorphic computing.

IRPS 2024 Main Conference

Reliability Assessment for an In-3D-NAND Approximate Searching Solution

computational ssd

in-memory approximate computing

3d-nand

**IRPS 2024 Tutorials were held in Dallas, Texas from April 14 to 15, 2024. The IRPS Reliability Year in Review (YIR) session consisted of three presentations reviewing the past year's reliability work by experts in the field for areas of high interest. It was a nice augmentation to the tutorials sessions immediately preceding and attendees were able to obtain keen reliability insights in short amount of time.**
