Cryogenic CMOS circuitry is inevitable to drive and read out qubits for the realization of scalable Quantum Computers (QCs). Analog circuits such as current mirrors and Digital-to-Analog Converter (DAC) are basic building blocks of the control circuits in QCs. In this work, we explore the impact of self-heating (SH) on 5 nm FinFETs and analog circuits for control electronics in QCs using cryogenic-aware BSIM-CMG compact model at both cryogenic and room temperatures.

IRPS 2024 Main Conference

Impact of Self-Heating in 5 nm FinFETs at Cryogenic Temperatures for Reliable Quantum Computing: Device-Circuit Interaction

5 nm finfets

self-heating

cryogenic
