Thermal behavior and its effect on RF large signal aging is extensively studied using Power Amplifier. While strong Iddq increase in linear region is seen, no significant change in RF is observed in compression. RF stress at three different VDD and Tj is reported. Thermal imaging results validate  TA Vs Tj  at Pdiss. Time domain peak voltage swings at different Tj demonstrate that HCIand off-state TDDB are key degradation mechanisms demonstrating excellent thermal behavior.

IRPS 2024 Main Conference

Thermal considerations on RF reliability and aging in SOI CMOS based Power Amplifiers

22fdx

rf reliability
