In this paper, we examine the impact of recently introduced low thermal budget HKMG treatments on stress-induced leakage current and defect generation in pMOS devices. We also conduct time-dependent dielectric breakdown measurements to analyze Soft-Breakdown behavior and compare extrapolated lifetimes with conventional high-performance logic devices. Additionally, we explore the effects of a new low-temperature treatment that enhances the quality of the high-k (HK) layer to meet high-temperature  TDDB standards.

IRPS 2024 Main Conference

SILC and TDDB reliability of novel low thermal budget RMG gate stacks

hkmg.

low thermal budget gate stack

dielectric breakdown

silc

3d integration
