Aerospike engines are a promising type of rocket engine with the potential to significantly improve the efficiency of rocket propulsion systems. Unlike traditional bell-shaped engines, aerospikes have a cone-shaped external contour that allows for more efficient combustion of the propellant in a variety of environmental conditions. The design of aerospike engines presents a challenging task due to their complex internal and external geometries. However, the recent advancements in additive manufacturing (AM) have made it possible to create these complex shapes with greater accuracy and precision. This contribution addresses the complete process&amp;nbsp;chain of an additively manufactured aerospike&amp;nbsp;breadboard engine using kerosene and hydrogen&amp;nbsp;peroxide as propellants. The aerospike was&amp;nbsp;fabricated by laser powder bed fusion (LPBF) using the&amp;nbsp;nickel-based superalloy INCONEL® 718. In order to&amp;nbsp;qualify the material and process for this application,&amp;nbsp;an extensive material characterization campaign&amp;nbsp;including density and roughness measurements,&amp;nbsp;tensile tests at room temperature, 700 °C and&amp;nbsp;900 °C, was conducted. In addition, various&amp;nbsp;geometric features such as triangles, ellipses and&amp;nbsp;circular shapes were generated to determine the&amp;nbsp;maximum unsupported overhang and geometric&amp;nbsp;accuracy. The results were taken into account in the&amp;nbsp;design maturation of the manifold and the cooling&amp;nbsp;channels of the aerospike breadboard engine. Postprocessing&amp;nbsp;included heat treatment, milling, turning&amp;nbsp;and eroding of interfaces, thermal barrier coating (TBC) of&amp;nbsp;thermally stressed surfaces and laser welding of&amp;nbsp;spike and shroud as well as quality assurance.

ICALEO 2023

Process Qualification, Additive Manufacturing, and Post Processing of a Hydrogen Peroxide / Kerosene Aerospike Breadboard Engine

process chain

post processing

aerospike

laser powder bed fusion

additive manufacturing

Aerospike engines are a promising type of rocket engine with the potential to significantly improve the efficiency of rocket propulsion systems. Unlike traditional bell-shaped engines, aerospikes have a cone-shaped external contour that allows for more efficient combustion of the propellant in a variety of environmental conditions. The design of aerospike engines presents a challenging task due to their complex internal and external geometries. However, the recent advancements in additive manufacturing (AM) have made it possible to create these complex shapes with greater accuracy and precision. This contribution addresses the complete process&nbsp;chain of an additively manufactured aerospike&nbsp;breadboard engine using kerosene and hydrogen&nbsp;peroxide as propellants. The aerospike was&nbsp;fabricated by laser powder bed fusion (LPBF) using the&nbsp;nickel-based superalloy INCONEL® 718. In order to&nbsp;qualify the material and process for this application,&nbsp;an extensive material characterization campaign&nbsp;including density and roughness measurements,&nbsp;tensile tests at room temperature, 700 °C and&nbsp;900 °C, was conducted. In addition, various&nbsp;geometric features such as triangles, ellipses and&nbsp;circular shapes were generated to determine the&nbsp;maximum unsupported overhang and geometric&nbsp;accuracy. The results were taken into account in the&nbsp;design maturation of the manifold and the cooling&nbsp;channels of the aerospike breadboard engine. Postprocessing&nbsp;included heat treatment, milling, turning&nbsp;and eroding of interfaces, thermal barrier coating (TBC) of&nbsp;thermally stressed surfaces and laser welding of&nbsp;spike and shroud as well as quality assurance.

technical paper

**General Chair Welcome**

![](https://assets.underline.io/markdown_image/1/image/d6e6dddc08bf2371b9136ea9c18dc5ab.png)

Welcome to ICALEO® 2023!

We were excited to host the world’s leading international conference on Lasers and Electro-Optics in Chicago. The Laser has been shown to have the potential to revolutionize solutions for major global challenges like energy usage and supply, global warming, and CO2 footprint. Even the fusion energy breakthrough is based on laser technology. The conference, with peer-reviewed scientific and technical presentations, focused on the newest results in Micro Applications, Macro Applications, Additive Manufacturing, Beam Shaping and Frontiers in Laser Applications. Additionally, the Battery-Manufacturing Track gave an overview of the process combined with the newest advances in laser application results.

The Business Session brought the business aspect and environment of the laser to the audience and the possibility to discuss with seasoned industry leaders from around the world.

Whether this is the first time you are hearing about ICALEO or you are a longtime attendee, you will find something of interest, new ideas, and an excellent opportunity to network with other laser specialists worldwide.

**Klaus Löffler **
ICALEO General Chair
Managing Director, Precitec GmbH

**What is ICALEO?**

ICALEO® brings together the brightest minds, seasoned professionals, and pioneering researchers from around the world. With a laser-focused agenda, ICALEO offers an exceptional platform to delve into the cutting-edge advancements, diverse applications, and transformative research that define lasers and electro-optics.

Participants will be immersed in a dynamic environment that fosters collaborative learning, networking, and idea exchange. Through engaging plenary presentations, technical sessions, an industry business panel, and networking events, attendees gain insights into the forefront of laser technology. From industrial applications to medical breakthroughs, additive manufacturing to materials processing, ICALEO covers the entire spectrum of laser-related disciplines. Moreover, the event serves as a launching pad for synergistic partnerships, paving the way for professionals to forge connections that shape the future of our industry.

Join us in Chicago and be part of an unparalleled gathering that challenges the boundaries of possibility within lasers and electro-optics. As we convene to share knowledge, explore innovations, and cultivate collaborations, ICALEO stands as a pivotal force driving the evolution of this transformative technology.

**Who attended?**

ICALEO is tailor-made for professionals, researchers, academics, and enthusiasts who are deeply passionate about the world of lasers and electro-optics. If you're an industry trailblazer, an academic luminary, an aspiring expert, or a postgraduate student looking to dive into the latest developments and trends, this is an event you won't want to miss.

Industrial leaders seeking to stay ahead of the curve in their fields, engineers working on laser applications, and manufacturing experts interested in additive manufacturing and materials processing will find ICALEO to be an invaluable platform. Researchers and scientists exploring the forefront of laser technology, from fundamental principles to groundbreaking applications, will also discover a wealth of knowledge and networking opportunities.

Medical professionals investigating laser-based medical advancements, entrepreneurs seeking to innovate with lasers, educators aiming to stay updated with the latest in laser education, and policy makers shaping the industry's landscape are all essential attendees. Whether you're an established expert or a rising star, the 42nd annual ICALEO promises to offer a diverse ecosystem of expertise, connections, and knowledge sharing that caters to the laser and electro-optics communities.

**Fields Represented:**

* Entrepreneurs and Innovators
* Manufacturing Experts
* Students and Graduates
* Policy Makers and Regulators
* Consultants and Advisors
* Technology Enthusiasts
* Suppliers and Manufacturers
* Startups and Innovators
* Researchers in Laser Education

**[View All Proceedings Here](https://icaleo.conferencespot.org/event-data)**

### **Program Tracks & Chairs**

To access the site please register [**here**](https://icaleo.org/attend).

Please register for the ICALEO 2023 Conference to join the event.

ICALEO® brings together the brightest minds, seasoned professionals, and pioneering researchers from around the world. With a laser-focused agenda, ICALEO offers an exceptional platform to delve into the cutting-edge advancements, diverse applications, and transformative research that define lasers and electro-optics.

The feedstock capture efficiency on powder laser directed energy deposition is becoming a big challenge on the industrial use of L-DED process for the manufacturing of large-scale AM parts. The powder capture efficiency is dependent of process optimization and the tool-path. The current literature presents a huge range of usual powder efficiency, between 3 – 32% and some specific cases exceeding 90%. The powder-gas jet stream interact with the laser beam adding material locally onto the substrate. Part of this material is captured by the melt pool. The not captured material is affected by the laser beam, causing a material degradation. There is a lack on the literature for studies on the reusability of powder on the L-DED process. This paper presents a comprehensive study on the consequence of laser interaction with SS 316L metal powder particles during the L-DED process using a range of different powder characterization techniques to access the powder morphology, particle size distribution, chemical composition, followability and particle porosity. The study was conducted within eight powder reuse cycles, without adding virgin material to the powder batch. Reduction of PSD range, increase of circularity, improvement on the powder flowability were identified as consequences of powder reuse. The consequence of the laser interaction with particles was further explored using SEM, presenting the continuous modification of the particles across the eight reuse cycles. The oxygen content of the particles was also measured to access the O2 pick-up as a consequence of particle heating.

Powder Degradation as a Consequence of Laser Interaction: A Study of SS 316L Powder Reuse on the Laser Directed Energy Deposition (L-DED) Process

Improving mechanical topology optimization (TO) results by substitution of biomimetic beams is one possibility to achieve designs of mechanical components that are highly sustainable and show good mechanical performance. Due to their geometric complexity such designs were found to be well suited for production by laser additive manufacturing.
One obstacle of incorporating biomimetics beams in TO designs is the lack of detailed design methodologies. [1] proposed a corresponding design concept. Building on their concept this work presents a detailed methodology for abstraction of TO results to a design consisting of ball nodes and cylindrical beams. Using such an auxiliary design, the internal forces and moments of the beams can be evaluated to allow for the substitution of suitable biomimetic beams to generate biomimetic component designs in a next step.
The work presents a skeletonization algorithm based on the potential field approach. Using the skeletonization and an additional analysis of the dimensions of the beams in the TO result, the algorithm develops an auxiliary design of the original TO result.
The final algorithm was applied to three common TO results to obtain one auxiliary component design, each. The developed algorithm was found to generate abstractions that were well-suited for use in the methodology proposed in [1] as internal forces and moments in the abstracted beams could be evaluated with low effort.
Therefore, the work contributes to a detailed design methodology for biomimetic mechanical components in the field of design for additive manufacturing (DfAM)

Development and Assessment of a Methodology for Abstraction of Topology Optimization Results to Enable the Substitution of Optimized Beams

The biggest challenges for laser-based powder bed fusion of metals (PBF-LB/M) are the slow production and the high part prices combined with process and component defects. Gaussian beams with fixed beam diameters and their characteristic high peak intensities are state-of-the-art in PBF-LB/M. However, Gaussian beams can cause spatter formation, keyholing, and resulting keyhole porosity due to evaporation of the melt. Laser beam shaping has been used in various publications for laser welding and PBF-LB/M to address the challenges mentioned above. Our research at the Professorship of Laser-based Additive Manufacturing focuses on developing beam-shaping technologies to improve the production speed and process quality in PBF-LB/M. The different beam shaping strategies we are evaluating are based on spatial light modulators (= change in wavefront due to local change in refractive index by tilting liquid crystals), acousto-optic deflectors (= ultra-fast deflection of the laser radiation by frequency change of acoustic sound waves), and a multi-core fiber concept (= change in relative intensity distribution via redistribution across fiber cross-section). The study will compare the performance of three different beam shaping technologies for PBF-LB/M and evaluate their design freedom and complexity. The aim is to use beam shaping to achieve a stable melt pool, increase production speed, and reduce resource and energy consumption.

Flexible and Highly Dynamic Beam Shaping Technologies for Additive Manufacturing

Despite the maturity of laser-based powder bed fusion of metals (PBF-LB/M), some barriers prevent the manufacturing process from fully being established in the industry. One drawback is spatter formation, which is disadvantageous to PBF-LB/M for three main reasons. First, adhering spatter can initiate coater collision, resulting in process failure. Second, large ad­hering spatter may cause lack-of-fusion defects as they require more energy to remelt sufficiently compared to unprocessed powder. Furthermore, big non-adhering spatter cannot be recycled as powder. The recycling of small spatter particles potentially results in degraded material properties. Ring-shaped beam profiles have been established for deep penetration welding to reduce spatter formation. Investigations on ring-shaped beam profiles in PBF-LB/M focus on improving productivity and process robustness. Quali­tative spatter reduction in PBF-LB/M using ring-shaped beam profiles has also been reported. This publication quantitatively examines the influence of ring-shaped beam profiles on spatter formation in PBF-LB/M. Image processing algorithms of on-axis high-speed images are utilized for spatter detection and tracking. A self-developed spatter segmentation is used to determine the spatter size. A Laplacian of Gaussian (LoG) filter is combined with a Kalman tracker to count and track the spatter. The results show that spatter formation is highly influenced by the beam profile and the chosen process parameters. Considering the melt track width, ring-shaped beam profiles could reduce the number of spatter per fused area. High numbers of spatter are generated when parameter sets result in balling. Moreover, spatter velocity is primarily dependent on the introduced dimensionless enthalpy.

Influence of Ring-Shaped Beam Profiles on Spatter Characteristics in Laser-Based Powder Bed Fusion of Metals

The surface tension of metals governs essential mechanisms in thermal processing techniques, including laser materials processing. For computational fluid dynamics accurate surface tension data are essential. Because of certain reasons like limitations to lower temperatures for existing surface tension measurement methods, and too few measurements, far too few data are available. A new method variant is proposed, to extend surface tension measurement to higher temperatures, up to the boiling temperature and even beyond. A laser beam generates a falling metal drop. From high-speed imaging, the oscillation frequencies of the free-falling drops can be measured and the surface tension can be derived. Two different methods are presented to generate the drop, single pulse laser melting of a suspended metal piece, then falling, and drop detachment from a laser molten metal wire tip. The approach, which will be developed stepwise, has also the aim to generate and measure a desired drop temperature to provide surface tension data as a function of temperature for different metal alloys. First results with iron sheets or with stainless steel wire show that drops with suitable oscillations can be generated but that certain challenges have to be solved. Sufficient recording duration is needed to take into consideration a higher frequency resolution and in turn accurate calculation by considering drop rotation and the third oscillation dimension. Laboratories equipped with a high-power laser, a high-speed camera and a temperature measurement instrument, e.g. a pyrometer, will be capable to measure desired surface tension values in an efficient manner.

Laser Generated Drops – Towards a Method Variant for Extended Surface Tension Measurement of Metals

Skin-pass rolls are used for setting the final sheet thickness and surface texture. For sheet metal that is produced for forming, textured skin-pass rolls featuring a high-low-structure are used in order to improve the formability and paint adhesion of the sheet. In this paper, new textures for skin-pass rolls generated by high-speed laser melt injection (HSLMI) are presented and characterized. Furthermore, it is studied how the texture of the roll is transferred to steel and aluminum sheets. With HSLMI, metal-matrix composite (MMC) layers featuring spherical fused tungsten carbide (SFTC) particles with a high hardness could be produced on skin-pass rolls. For generating an increased high-low structure, laser ablation and electrolytic etching were carried out after HSLMI and grinding of the rolls. An analysis of the topography showed that different height differences between SFTC particles and matrix can be set. The textures generated by laser ablation showed a topography featuring two height levels, whereas a texture with spherically-shaped particles could be generated by electrolytic etching. Furthermore, it was found that all textures were transferred from the roll to both steel and aluminum sheets. The transfer of the textures mainly depended on the roughness and the SFTC particle content of the roll.

Texturing Skin-Pass Rolls by High-Speed Laser Melt Injection, Laser Ablation and Electrolytic Etching

The use of air bubbles injected into viscous fluid flows to reduce frictional drag has been extensively studied for industrial applications, especially in the marine industry. However, the lack of control over air bubble stability, size, and shape has limited its widespread adoption. This research explores the use of laser-based surface wettability modification techniques to enhance control over air bubble behavior in water flows.
Using nanosecond laser and chemical immersion, metal plates were processed to create wettability patterns consisting of superhydrophobic and superhydrophilic regions. Water tunnel experiments were conducted to observe the behavior of air bubbles over different wettability patterns. The results show that surface wettability can be used to control the size and spatial distribution of air bubbles, potentially enhancing the energy cost-benefit of drag reduction methods in the marine industry. Small circular bubbles were retained over untreated and hydrophilic surfaces, while immediate bubble coalescence was observed over superhydrophobic surfaces.
Computational fluid dynamics (CFD) modeling was also performed to verify and further understand the role of surface wettability. The results demonstrate the potential of laser-based surface wettability modification as a solution for improving the control of air bubble behavior in large-scale applications. This research provides insights into the feasibility of laser-based surface wettability modification as a novel approach for controlling air bubble behavior in water flows and improving the efficiency of drag reduction methods.

Enhancing Control of Air Bubbles in Water Flows through Laser-based Surface Wettability Patterning

With the ever-growing global demand for renewable energy sources, Cu2ZnSnS4 (CZTS) thin films can complement the existing Silicon-based photovoltaic (PV) cell market. However, low carrier mobility and lifetime, non-uniformity, and defects in the film structure have reduced the widespread application of CZTS. During the manufacture of CZTS solar cells, the initial as-deposited films have a nanocrystalline structure. Therefore post-deposition annealing is critical to make the efficiency of the cell commercially viable. Conventional furnace annealing methods have failed to enable this technology's commercialisation, and the heating of the complete PV cell limits the selection of available substrates. This research explored alternative approaches, specifically diode and pulsed fibre laser annealing for CZTS films deposited on flexible Mo foils in different gas atmospheres. SEM, XRD, and Raman spectroscopy techniques were used to analyse the laser-annealed samples. Processing parameters were established by which grain enlargement was observable with the pure CZTS phase retained. The key findings build confidence in laser annealing as an alternative method to enhance the crystallinity, surface morphology, chemical composition, and electrical properties of CZTS thin films for next-generation PV cells. Laser annealing can potentially reduce the reliance on vacuum furnace heating of PV cells and enable annealing on more thermally sensitive substrates.

Exploring Laser Annealing as an Alternative Approach to Improve CZTS Thin Film Quality for Photovoltaic Cells

Selective copper generation on polymers by reductive laser sintering represents an advantageous alternative to conventional mask-based approaches such as lithography or processes based on noble metals. A variety of applications in sensing, thermoelectronics and optoelectronics have already been demonstrated. For laser sintering, ultrashort-pulsed lasers enable precise control of the introduced energy and a reduced heat-affected zone. In turn, this type of laser can also be used to implement other processes such as ablation, modification, or the integration of embedded microfluidics and micro-optical systems. In previous studies, copper patterns with high spatial resolution have been achieved by using microscope objectives. However, design of microelectronic circuits also consists of broad conductive paths and contact areas, which result in time-consuming processing when hatching fine lines. The use of galvanometric scanners with long focal length lenses results in larger focal diameters that enable faster processing. However, this is also accompanied by higher laser powers, loading the heat-sensitive substrates and promoting reoxidation of the resulting copper structures, which can dramatically increase the achieved resistivities.
Against this background, we report on the possibility to accelerate femtosecond reductive laser sintering of copper(II) oxide on the surface of transparent cyclic olefin copolymers by varying the focus size. By using different focusing conditions, different process speeds are achieved and the structural accuracies are controlled. The generated copper layers are investigated using scanning electron microscopy, energy-dispersive X-ray spectroscopy and 4-tip resistivity measurements to achieve high copper content at low resistivities in the resulting copper films at increased metallization rate.

Acceleration of Femtosecond Reductive Laser Sintering of Copper(II) Oxide for Conductive Copper Patterns on Cyclic Olefin Copolymers

Localized metallization of flexible and rigid dielectric materials is a powerful tool for surface engineering and modification. Metallic patterns are of great interest in various fields of science and technology, where they can find applications in the production of electronics, sensor devices, etc.&nbsp; Along with this, the vector of modern industrial microelectronics technologies is shifting annually towards the development and application of more environmentally friendly approaches.
Deep eutectic solvents have been gaining popularity for the last 10 years as “green” solvents. Thus, the use of such systems seems extremely relevant, taking into account the replacement of traditional approaches with more environmentally friendly ones.
We present a new approach based on deep eutectic solvents (DES)-assisted synthesis of conductive copper structures using regular technique of laser-induced liquid deposition of metals (LCLD). It was shown that it is possible to increase the deposition rate of copper by an order of magnitude by using deep eutectic solvents (DESs) as a medium for laser synthesis.&nbsp; As a results, the developed approach overcomes the previous limitations of the one-stage laser-assisted deposition technology, and opens the opportunities for new applications of this method, e.g. in micro-LEDs and displays technologies. We anticipate further development of this approach for fabrication of a wide range of conductive materials on various substrates with higher deposition rate.
