Gallium oxide has rapidly advanced as a material for high-power electronics and optically blind photodetectors, due not only to its wide band gap and availability of melt-grown substrates, but also its dopability with n-type doping being demonstrated from 1014 cm-3-1022 cm-3. However, numerous reports have shown dopant compensation when annealing in temperatures greater or equal to 1000 oC. To further device development, it is critical to understand the compensation mechanism, and to study defect formation and diffusion. It is of course difficult to study the diffusion of native defects such as gallium vacancies (VGa); typically isotope diffusion experiments are conducted. It is also of high interest to investigate the mechanisms by which native defects are introduced; does the material generate them homogeneously in its bulk or are they generated at surfaces? Do vacancies diffuse alone or as complexes with other defects? We sought an alternate method to determine the introduction and diffusion of Ga vacancies. We began with the hypothesis that Al could be used as a tracer for cation vacancy diffusion because of the assumption that Al would diffuse primarily substitutionally via cation vacancies. We designed superlattices of alternating epitaxial layers of Al0.1Ga1.9O3 / Ga2O3 deposited on both Sn- and Fe-doped (010) β-Ga2O3 substrates. The presence of many repeated layers diffusing during the same experiment can be used to reveal gradients in the diffusion constant vs depth and time, which in turn can indicate the direction of vacancy flux from the source. Dynamic Secondary Ion Mass Spectrometry (D-SIMS) profiles were collected before and after annealing in O2 at 1000-1100 oC. A novel transient simulation of vacancy- mediated diffusion was developed in Matlab to model the evolution of Al profiles under different scenarios of transient vacancy diffusion. A surprising finding is that there was no evidence of vacancy injection from the free surface, but that a large flux of vacancies flows into the superlattices from Sn-doped substrates. In the case of superlattices on Fe-doped substrates, no such flux is detected and the diffusion constant of Al is uniform and much smaller in depth, consistent with smaller uniform vacancy concentrations or other non-vacancy-mediated diffusion mechanisms. We present our results for the diffusion constant of VGa or its dominant complex mediating Al diffusion as well as the diffusivity for Al by the vacancy mechanism. The role of macroscopic crystallographic defects on the diffusion results was explored via ToF-SIMS 3D reconstructions and shown to be negligible under well-chosen conditions. Meanwhile, we also investigated the diffusion of Sn and Fe from the wafers into the superlattices. We provide a lower bound for the Sn diffusion coefficient, and discuss the strong possibility that it retards the diffusion of VGa by complexation. Fe profiles are very complex and evolve via multiple diffusion channels. We provide the diffusion coefficient for the slower channel, and model the faster surface pile-up by interaction with surface potential.

EMC 2023

Measuring Diffusion of Al, Sn, and Fe in Ga2O3 Using β-(Al,Ga)2O3/Ga2O3 Superlattices

ga2o3

diffusion

modelling
