We present a simple composite analytical model that covers the entire electric-field range with excellent accuracy, with the use of an empirically-derived extrapolation function in the TFE-to-FE transition region. The composite TE-TFE-FE model successfully bridges the gap between TFE and FE regimes, allowing for accurate modeling of the Schottky barrier reverse current across the entire electric-field range. The closed-form and local nature of the composite model allows for easy implementation in TCAD tools for device design and analysis.

DRC 2022

A Composite TE-TFE-FE Model for Schottky Barrier Reverse Current over the Entire Electric-Field Range

reverse leakage current; schottky barrier diode; field emission
