A versatile but extremely compact memristor model is introduced that is capable of emulating various memristive technologies while featuring fully analog, flux-linkage controlled operation as well as temporal tunability. Computation with time is a layer of complexity that could help break through barriers in the field of non-traditional compute and is extremely bio-mimetic, as the brain is exceptionally adept at temporal processing. This talk will explore some examples of temporal computation using simulated memristive hardware.

DRC 2022

An Experimentally Validated, Universal Memristor Model Enabling Temporal Neuromorphic Computation

biomimetic

temporal

brain

memristors

computation

neuromorphic

model
