Robots are increasingly deployed to solve complex real-world tasks that require  continuous processing of their observations only to be constrained by their on-board resources.  Energy-efficient control of mobile robots is one of the limiting factor in having robots deployed  to perform in-space assembly of structures. Spiking Neural Networks (SNNs) deployed on  neuromorphic processors provide an energy-efficient solution that could also facilitate building  intelligence similar to living creatures for robots.
Neuromorphic architectures imitate the behavior and function of biological nervous  systems by implementing networks of artificial neurons and synapses that benefit from low  power consumption. These computing platforms emulate their biological counterparts by  distributing both computation and memory among a large number of computation units, each  passing information, via asynchronous spikes, to hundreds or thousands of other computational  units, like neurons would do through synapses.
Over time, different digital neuromorphic architectures like Intel’s neuromorphic  technology, code named Loihi [1], have replicated many characteristics of SNNs in hardware.  Despite the advantages of neuromorphic hardware (e.g., high speed and energy efficiency)  there are few algorithms that utilize it for in situ robot control. Recent work by Michaelis et al. [2], proved the theoretical feasibility of using Intel’s neuromorphic technology for trajectory  generation on hardware, but fails to employ the strategy with robotic hardware (simulated or in  situ). Michaelis’ work presents a biologically plausible approach that also promised a control  relevant timescale.
His work is based on Reservoir Computing, specifically, Liquid State Machines,  implemented as biologically plausible anisotropic networks. In Michaelis’ work for trajectory  generation, the liquid layer is implemented as an anisotropic network, based on a biologically
inspired rule for forming spatially asymmetric non-plastic connections, similar to the ones that  have been observed to activate in human and mammal brains [3]. It is believed that correlated  spatial anisotropic connectivity is what makes learning faster and more efficient. Michaelis et
Distribution A — Approved for public release, distribution is unlimited
al. [2], make use of this anisotropic network idea from Spreizer et al. [3] and show the feasibility  of using an architecture that integrates it for trajectory generation.
In this work we close the gap between theoretical formulation and practical applications  by implementing the missing components to enable Kinova Gen3, a 7 degree of freedom  robotic arm, to use this type of neural network on Intel Kapho Bay Loihi for trajectory  generation.
Demonstrating neuromorphic capabilities for robotic control is of high interest at NRL  due to the appeal of high performance and energy efficiency that neuromorphic hardware  presents. The success of this strategy has a big impact on different projects at NRL that are investigating: neuromorphically controlled multi-limbed robotic systems for Naval ship  maintenance tasks, neuromorphically controlled multi-limbed space truss walking robot that  can autonomously assemble truss elements to construct large space structures in orbit, and the  capabilities of memristor-based neuromorphic processors.

References:

[1] Davies, M., Srinivasa, N., Lin, T.-H., Chinya, G., Cao, Y., Choday, S. H., et al. “Loihi: a  neuromorphic manycore processor with on-chip learning.” IEEE Micro (2018).
[2] Michaelis, Carlo, Andrew B. Lehr, and Christian Tetzlaff. “Robust trajectory generation for  robotic control on the neuromorphic research chip Loihi.” Frontiers in neurorobotics 14 (2020).
[3] Spreizer, Sebastian, Ad Aertsen, and Arvind Kumar. “From space to time: Spatial  inhomogeneities lead to the emergence of spatiotemporal sequences in spiking neuronal  networks.” PLoS computational biology 15.10 (2019).
Distribution A — Approved for public release, distribution is unlimited
*

NAML 2022

Neuromorphic Hardware Anisotropic Reservoir Trajectory Generation and execution with Robotic Arm

anisotropic network

robot control

manipulation

neuromorphic computing

spiking neural network
