Fast reorientation of space-based sensors is needed to increase ISR capacity and to respond to high-value targeting requests. Rapid reorientation maneuvers are realized by constructing and solving a nonlinear optimization problem that models the physics of the rotational motion as part of the ground process of mission operations. The solution trajectories are then uplinked to the spacecraft for attitude guidance. Attitude guidance commands for a spacecraft are a time-series of incremental rotations that are given to the attitude control system at the closed-loop feedback rate which is typically greater than 10 Hz.

In practical space systems, it is generally not possible to uplink reorientation commands as a finely sampled time-series (at or greater than 10 Hz) since this would quickly exhaust the capacity of a spacecraft’s command buffer. Instead, the current paradigm is to issue a reorientation command as a single time-tagged target orientation. Then, an on-board trajectory generator is used to construct an appropriate rotation command time-series at the closed-loop feedback rate which are then fed to the attitude guidance system. Typically, these on-board trajectory generators do not have the processing power to perform trajectory optimization and instead generate a feasible, but sub-optimal, time-series command set at the appropriate rate.

A potential solution to this problem is to compute and then compress the optimized time-series commands using an autoencoder. An autoencoder is an unsupervised machine learning application of a neural network that conducts a non-linear mapping of the inputs to a lower dimensional space, called the latent space, using the encoder portion of the autoencoder. It then reconstructs the same input from the latent space using the decoder portion of the autoencoder. With such a method, the optimized command sequence can be generated and encoded on the ground, then only the latent space is transmitted to the spacecraft and decoded on-board the spacecraft resulting in the reconstructed optimized rotation sequence at the closed-loop feedback rate. Given the time-series nature of the optimized command sequence, one appropriate architecture for the autoencoder is a long short term memory (LSTM) neural network autoencoder.

In this talk, we demonstrate the methodology for constructing and training the LSTM autoencoder and show the reconstruction error for different degrees of compression represented by decreasing dimensionality of the latent space. We then compare the reconstructed command sequence and the uncompressed time-optimal solutions using a flight simulation software at the closed-loop feedback rate. The result is a new and computationally efficient approach for implementing non-legacy maneuvers on board a spacecraft. There are numerous applications beyond spacecraft where this capability can benefit the DoD such as small unmanned vehicle operations and operations in degraded electromagnetic environments.

NAML 2022

A Method to Compress and Transmit Optimal Reorientation Commands to a Spacecraft Using Long Short-Term Memory Neural Network Autoencoders

spacecraft

long short-term memory neural network

autoencoder
