In this work, we demonstrate that proper engineering of VTH in ferroelectric FET is necessary to ensure correct array operation for in-memory computing applications. We highlight that for all current-based computing operations, it is necessary to keep both the low-VTH and high-VTH states positive to cut off the leakage for grounded unselected cells. To reach that design target, we systematically evaluate various design options for VTH engineering, including the gate metal work function, the body bias, and the buried oxide thickness, using calibrated TCAD. We establish the design guidelines for VTH engineering to ensure the successful operation of in-memory computing.

IRPS 2022 Main Conference

Ferroelectric FET Threshold Voltage Optimization for Reliable In-Memory Computing

tcam

fdsoi ferro fet memories

in-memory computing
