We propose a novel method of predicting electron and hole lateral diffusion in a charge trapping layer of 3D TLC NAND by which we can estimate the long-term lateral migration (LM) behavior in a short time. By monitoring the threshold voltage change (△Vth) of the select cell under various bias and temperature conditions, we observe that electron and hole lateral diffusivity matches well with the Poole-Frenkel (PF) model. The lateral diffusivity is extracted by measuring △Vth when the electrons and holes of neighboring cells reach the selected cell.

IRPS 2022 Main Conference

Electric Field Impact on Lateral Charge Diffusivity in Charge Trapping 3D NAND Flash Memory
