p-GaN gate HEMTs are attractive transistor structures for power electronics. For reliability and sidewall leakage reasons, it is desirable for the p-GaN layer to extend beyond the edges of the gate metal contact and form an offset. While experimental studies demonstrate wealthy PBTI effects in p-GaN HEMTs, a detailed study of the impact of the p-GaN offset length on device PBTI has yet to be done. Our study reveals a new permanent PBTI degradation mechanism that uniquely takes place in long offset regions that can compromise transistor reliability. We attribute this degradation mechanism to incomplete Mg activation during thermal annealing.

IRPS 2022 Main Conference

Impact of Gate Offset on PBTI of p-GaN Gate HEMTs
